Каталог запасных частей к технике: SEM921. Front Control Console
1
2
3
4
5
6
7
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
31
32
33
34
35
36
37
38
39
40
41
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
60
61
62
63
64
65
66
67
68
69
70
70
71
72
73
74
75
77
78
79
80
81
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5186583 | Nut | |
| 2 | 5188246 | Bolt | |
| 3 | 5530667 | Manual accelerator handle | |
| 4 | 1643562 | Throttle lock mechanism | |
| 5 | 5530662 | Manual accelerator rocker arm | |
| 6 | 5178659 | Gasket | |
| 7 | 5186584 | Nut | |
| 9 | 5246918 | Bolt | |
| 10 | 5530696 | Washer | |
| 11 | 8D5641 | Washer | |
| 12 | 5530654 | Bushing | |
| 13 | 5530655 | Bushing | |
| 14 | 5530647 | Cover plate | |
| 15 | 5536170 | Steering pole assembly | |
| 16 | 5189742 | Washer | |
| 17 | 5183667 | Threaded screw | |
| 18 | 5530694 | Plate | |
| 19 | 5530686 | Upper cap | |
| 20 | 5530646 | Cover plate | |
| 21 | 5530685 | Plate | |
| 22 | 5650251 | Washer | |
| 23 | 5182308 | Bolt | |
| 24 | 5530712 | Bearing sleeve | |
| 25 | 5536208 | Bearing | |
| 26 | 5530705 | Bushing | |
| 27 | 5530674 | Rocker arm | |
| 28 | 5530658 | Tension rod | |
| 29 | 5182098 | Gasket | |
| 31 | 5530656 | Tension rod | |
| 32 | 5530677 | Shaft | |
| 33 | 5536210 | Splinted | |
| 34 | 8T1174 | Seal ring | |
| 35 | 5569435 | Tension rod | |
| 36 | 5530693 | Washer | |
| 37 | 5530689 | Washer | |
| 38 | 5536209 | Bearing | |
| 39 | 1293173 | Bolt | |
| 40 | 5569436 | Pedal | |
| 41 | 5569437 | Pedal | |
| 43 | 5202592 | Bolt | |
| 44 | 5530683 | Throttle control drive shaft | |
| 45 | 5530707 | Retainer | |
| 46 | 5530715 | Spring tension rod | |
| 47 | 5530680 | Tension rod | |
| 48 | 5649650 | Washer | |
| 49 | 5188390 | Bolt | |
| 50 | 5221990 | Yoke | |
| 51 | 5189745 | Washer | |
| 52 | 5390942 | Pin mandrel | |
| 53 | 5530678 | Rocker arm | |
| 54 | 5530679 | Tension rod | |
| 55 | 5530659 | Pedal | |
| 56 | 5530706 | Rocker arm | |
| 57 | 5530651 | Cover plate | |
| 58 | 5530653 | Cover plate | |
| 59 | 5530699 | Steering fixed plate | |
| 60 | 5189744 | Washer | |
| 61 | 5186570 | Threaded screw | |
| 62 | 5649643 | Bolt | |
| 63 | 5530682 | Tension rod | |
| 64 | 5530663 | Radiator | |
| 65 | 5182310 | Bolt | |
| 66 | 5530703 | Spacer sleeve | |
| 67 | 5207689 | Joint bearing | |
| 68 | 5182018 | Bushing | |
| 69 | 5530684 | Drive shaft | |
| 70 | 5178605 | Spine | |
| 71 | 5188389 | Bolt | |
| 72 | 5547460 | Retainer | |
| 73 | 5530681 | Rocker arm | |
| 74 | 5184420 | Washer | |
| 75 | 5227810 | Handle | |
| 76 | 5530690 | Hol low shaft | |
| 77 | 5530714 | Spacer sleeve | |
| 78 | 5530697 | Plate | |
| 79 | 5243214 | Cotter pin | |
| 80 | 5530713 | Seal sleeve | |
| 81 | 5536245 | Steer wheel | |
| 82 | 5530652 | Cover plate | |
| 83 | 5530702 | Base | |
| 84 | 5182310 | Bolt | |
| 85 | 5530644 | Air spring base | |
| 86 | 5186585 | Nut | |
| 87 | 5530688 | Bearing end cap |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
