Каталог запасных частей к технике: SEM919. Electric System
1
2
3
4
5
6
7
8
9
10
11
11
11
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5386541 | Back up alarm | |
| 2 | 5189653 | Engine negative wire | |
| 3 | 5211180 | Speed sensor | |
| 4 | 5384862 | Sensing for temperature | |
| 5 | 5384858 | Low air pressure switch | |
| 6 | 5529780 | Rear frame harness as | |
| 7 | 5384864 | Parking swimming | |
| 8 | 5386503 | Scrubber | |
| 9 | 5386520 | Switch as-pressure | |
| 10 | 5529778 | Floor harness as | |
| 11 | 5189640 | Work lamp | |
| 12 | 5549793 | Control box | |
| 13 | 5549817 | Air pressure gauge | |
| 14 | 5537619 | Hose-air pressure | |
| 15 | 5529779 | Front frame harness as | |
| 16 | 5189628 | Monotone horn | |
| 17 | 5386529 | Front wiper | |
| 18 | 5529783 | Cab harness as | |
| 19 | 5386631 | Radio | |
| 20 | 5531478 | Bracket | |
| 21 | 5821856 | Panel | |
| 22 | 1321829 | Buzzer | |
| 23 | 5537620 | Hose-air pressure | |
| 24 | 5529784 | Wiring gp-front console | |
| 25 | 5549821 | Throttle pedal | |
| 26 | 5242220 | Key switch | |
| 27 | 5546336 | Cigar lighter | |
| 28 | 5241616 | Fan | |
| 29 | 5192422 | Dome lamp | |
| 30 | 5529777 | Switch harness as | |
| 31 | 5531450 | Water in fuel sw harness | |
| 32 | 5242224 | Brake lamp switch | |
| 33 | 5533812 | Bracket | |
| 34 | 5189629 | Dc contactor | |
| 35 | 5386523 | Fuel amount sensing | |
| 36 | 5549819 | Sensor-transmission pressure | |
| 37 | 5529781 | Rear lamp harness as | |
| 38 | 5529770 | Rear work light support | |
| 39 | 5241610 | Rear comb lamp |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
