Каталог запасных частей к технике: SEM919. Control Valve Group
10
20
24
30
50
60
70
80
100
120
120
140
150
154
154
160
260
270
280
290
350
360
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 5364449 | 5364449 | Control valve group | |
| 5371479 | 5371479 | Solenoid valve | |
| 10 | Down Bulkhead | Down bulkhead | |
| 20 | Gasket | Gasket | |
| 24 | Gasket | Gasket | |
| 30 | Fuel Transfer Plate | Fuel transfer plate | |
| 50 | Throttle Nozzle | Throttle nozzle | |
| 55 | Throttle Nozzle | Throttle nozzle | |
| 60 | Steel Ball | Steel ball | |
| 70 | Spring | Spring | |
| 80 | 5531341 | Hex socket head threaded screw | |
| 100 | 5182430 | Hex socket head threaded screw | |
| 120 | 5522639 | Hex socket head threaded screw | |
| 140 | W43002640 | Up bulkhead | |
| 150 | 5753321 | Gasket | |
| 154 | 5753322 | Gasket | |
| 160 | 5182430 | Hex socket head threaded screw | |
| 180 | 5757323 | Hex socket head threaded screw | |
| 260 | W43002670 | Plug | |
| 270 | 5776772 | Copper washer | |
| 280 | Threaded Screw | Threaded screw | |
| 290 | Copper Washer | Copper washer | |
| 350 | Plug | Plug | |
| 360 | Copper Washer | Copper washer |
