Каталог запасных частей к технике: SEM669C. MAIN REDUCER AND DIFFERENTIAL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B040911020 | Bolt | |
| 2 | B041011255 | Bolt | |
| 3 | B041011450 | Bolt | |
| 4 | B060111003 | Lock washer | |
| 5 | B060111203 | Lock washer | |
| 6 | B060111404 | Washer | |
| 7 | B060112206 | Washer | |
| 8 | B070214002 | Snap ring | |
| 9 | B120330004 | Bearing | |
| 10 | B120400016 | Bearing | |
| 11 | B120400017 | Bearing | |
| 12 | B160130560 | O-ring | |
| 13 | B160220004 | Seal ring | |
| 14 | B160240004 | Seal ring | |
| 15 | Z610240470 | Bearing seat | |
| 16 | Z610240480 | End cover | |
| 17 | Z610240491 | Apron | |
| 18 | Z610240501 | Adjusting washer | |
| 19 | Z610240510 | Lock nut | |
| 20 | Z610240520 | Washer | |
| 21 | Z610240540 | Cover | |
| 22 | Z610240560 | Adjusting washer | |
| 23 | Z610240570 | Bearing sleeve | |
| 24 | Z610240580 | Adjusting washer | |
| 25 | Z630500090 | Spiral bevel driving gear (r) front axle | |
| 25 | Z630500101 | Spiral bevel driving gear(l) front axle | |
| 25 | Z630500110 | Spiral bevel driving gear(r) rear axle | |
| 25 | Z630500121 | Spiral bevel driving gear(l) rear axle | |
| 26 | Z610240700 | Differential nut | |
| 27 | Z610240720 | Lock plate | |
| 28 | Z610240770 | Connect bolt on differential frame | |
| 29 | Z610240780 | Nut | |
| 30 | Z610240790 | Lock washer | |
| 31 | Z610240850 | Shim | |
| 32 | Z610240860 | Shim | |
| 33 | Z610240870 | Shim | |
| 34 | Z610240880 | Shim | |
| 35 | Z610240890 | Shim | |
| 36 | Z610240900 | Shim | |
| 37 | Z610240910 | Shim | |
| 38 | Z610240920 | Shim | |
| 39 | Z610240930 | Sh m | |
| 40 | Z610240940 | Sh m | |
| 41 | Z610240950 | Sh m | |
| 42 | Z610240960 | Stud | |
| 43 | Z610241090 | Pin | |
| 44 | Z620590270 | Flange | |
| 45 | Z62059062 | Shim | |
| 46 | NZ6205912200 | Case | |
| 47 | NZ6205912200 | Differential bearing bracket cover | |
| 48 | NZ62059005020 | Differential assembly | |
| 48 | NZ62059005030 | Differential |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
