Каталог запасных частей к технике: SEM669C. ELECTIRCAL SYSTEM
1
2
4
6
8
9
10
11
13
14
18
19
20
24
25
26
27
28
29
30
31
32
33
34
35
39
40
41
42
43
44
45
47
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| W110007020 | W110007020 | Reversing lamp bulb | |
| W370002000B | W370002000B | Far and near bulb | |
| W370002100B | W370002100B | Traveling crane bulb | |
| W370001920B | W370001920B | Braking lamp bulb | |
| W110010190 | W110010190 | Steering indicating light | |
| 1 | W110001370 | Clip | |
| 2 | W370001910B | Front combine lamp | |
| 4 | W370000020A | Ceiling lamp | |
| 6 | W370000440B | Parking braking pressure switch | |
| 8 | Z5B55000400 | Switch harness | |
| 9 | W370000160B | Fan | |
| 10 | W370000400B | Gear box oil pressure switch | |
| 11 | W370000410B | Temperature sensor | |
| 13 | W370000390B | Hydraulic oil pressure switch | |
| 14 | Z6B55000400 | Engine temperature connection fitting | |
| 15 | B060410501 | Washer | |
| 16 | B060110501 | Lock washer | |
| 17 | B010210510 | Screw | |
| 18 | W370001960B | Oil measure sensor | |
| 19 | W3700000790B | Rear combine lamp | |
| 20 | Z5A02102200 | Cover for harness | |
| 21 | B040911020 | Bolt | |
| 22 | B060111003 | Lock washer | |
| 24 | W110024070 | Main power switch | |
| 25 | W370000770B | Backup alarm | |
| 26 | W370000780B | Rear combine lamp | |
| 27 | W46000010 | Battery | |
| 28 | W110024960 | Cover for positive terminal | |
| 29 | Z3A02101700 | Battery negative cable | |
| 30 | W110025560 | Disconnected switch | |
| 31 | Z5B557004 | Battery negative cable assembly | |
| 32 | Z5B55000900 | Battery connect cable | |
| 33 | W110024810 | Battery terminal clamp | |
| 34 | W46000044 | Negative boot | |
| 35 | Z5B557002 | Gear box control harness assembly | |
| 39 | W110009610 | DC contactor | |
| 40 | W370000070 | Cover | |
| 41 | Z5B557003 | Starter battery cable assembly | |
| 42 | Z5B55001400 | Engine safety cable | |
| 43 | B060111203 | Lock washer | |
| 44 | B040911230 | Bolt | |
| 45 | W370000370B | Gauge panel | |
| 47 | Z320210020 | Cover for harness | |
| 48 | W370001900B | Front lamp |
