Каталог запасных частей к технике: SEM656D. Steering Hydraulic System
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
66
67
68
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5823607 | Screw | |
| 2 | 5183661 | Screw | |
| 3 | 5533520 | Bolt | |
| 4 | 5189591 | Bolt | |
| 5 | 5649636 | Bolt | |
| 6 | 5649639 | Bolt | |
| 7 | 5182309 | Bolt | |
| 8 | 5182310 | Bolt | |
| 9 | 5182311 | Bolt | |
| 10 | 5383136 | Bolt | |
| 11 | 5186585 | Nut | |
| 12 | 5189737 | Washer | |
| 13 | 5184417 | Washer | |
| 14 | 5184418 | Washer | |
| 15 | 5184420 | Washer | |
| 16 | 5216761 | O ring | |
| 17 | 5216764 | O ring | |
| 18 | 5216769 | O ring | |
| 19 | 5216771 | O ring | |
| 20 | 5216773 | O-ring | |
| 21 | 5216774 | O ring | |
| 22 | 5188766 | Clamp | |
| 23 | 5227739 | Steering cylinder | |
| 24 | 5227742 | Clip | |
| 25 | 5190318 | Adapter | |
| 26 | 5190333 | Connection fitting | |
| 27 | 5227742 | Clip | |
| 28 | 5190340 | Union-orfs to orp | |
| 29 | 5190342 | Adapter | |
| 30 | 5190393 | Adapter | |
| 31 | 5227798 | Pump | |
| 32 | 5227802 | Steering valve | |
| 33 | 5227804 | Parker cartridge | |
| 34 | 5194965 | One-pipe clip | |
| 35 | 5209863 | Hollow bolt | |
| 36 | 5190427 | Connection joint | |
| 37 | 5573329 | Double hose clip | |
| 38 | 5245652 | Rear fittings steering cylinder | |
| 39 | 5245654 | Front fittings left steering | |
| 40 | 5245658 | Right steering cyl-front fittings | |
| 41 | 5245660 | Connection fitting | |
| 42 | 5245661 | Rear fittings of right steering | |
| 43 | 5227789 | Priority valve fittings | |
| 44 | 5190434 | Tube clip | |
| 45 | 5245665 | Support | |
| 46 | 5245666 | Steering oil fittings assembly | |
| 47 | 5245667 | 3-line clamp | |
| 48 | 5245668 | High pressure hose assembly | |
| 49 | 5190435 | Spacer | |
| 50 | 5245728 | Pipe | |
| 51 | 5245735 | High pressure hose assembly | |
| 52 | 5247531 | Hose as. | |
| 53 | 5247533 | Tube as. | |
| 54 | 5247535 | Hose as. | |
| 55 | 5247537 | Plate | |
| 56 | 5247538 | Suction tube as. | |
| 57 | 5247540 | Suction hose | |
| 58 | 5247541 | Hose as. | |
| 59 | 5247543 | Hose as. | |
| 60 | 5247545 | Hose as. | |
| 61 | 5247547 | Hose as. | |
| 62 | 5247549 | Hose as. | |
| 63 | 5247551 | Inlet block | |
| 64 | 5247554 | Oil block | |
| 65 | 5247587 | Bracket as. | |
| 66 | 5247591 | Hose as. | |
| 67 | 5247595 | Hose as. | |
| 68 | 5573319 | Split flange |
