Каталог запасных частей к технике: SEM656D. Gearbox As.
1
1
2
2
3
3
4
4
5
6
7
8
9
9
10
11
11
12
13
13
14
14
15
16
17
18
21
22
23
25
41
42
43
44
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5243217 | Cotter | |
| 2 | 5238420 | Nut | |
| 3 | 5225154 | Plate | |
| 4 | 5225155 | O ring | |
| 5 | 5225160 | Flange | |
| 6 | 5182319 | Bolt | |
| 7 | 5211361 | Washer | |
| 8 | 5225159 | Bearing seat | |
| 9 | 5383074 | Seal | |
| 10 | 5383069 | O ring | |
| 11 | 5219952 | Bearing | |
| 12 | 5243208 | Retainer | |
| 13 | 5225161 | Sleeve | |
| 14 | 5225156 | Plate | |
| 15 | 5225158 | Gear | |
| 16 | 5238421 | Sleeve | |
| 17 | 5225157 | Sleeve | |
| 18 | 5225153 | Output shaft | |
| 19 | 5225152 | Gear | |
| 20 | 5230984 | Plate | |
| 21 | 5238446 | Fiiter | |
| 22 | 5216774 | O ring | |
| 23 | 5225754 | Oil drain screw | |
| 24 | 5225140 | Ruller | |
| 25 | 5230989 | Plate | |
| 26 | 5234324 | Flange | |
| 27 | 5219947 | Bolt | |
| 28 | 5186588 | Nut | |
| 29 | 5225164 | Washer | |
| 30 | 5219955 | Bearing | |
| 31 | 5197589 | Retainer | |
| 32 | 5225144 | Cover | |
| 33 | 5383078 | Seal | |
| 34 | 5547105 | Flange | |
| 35 | 5225148 | O ring | |
| 36 | 5225147 | Plate | |
| 37 | 5225141 | Nut | |
| 38 | 5243221 | Pin | |
| 39 | 5188387 | Bolt | |
| 40 | 5189730 | Washer | |
| 41 | 5227248 | Adapter | |
| 42 | 5487327 | Breather | |
| 43 | 5202593 | Bolt | |
| 44 | 5189745 | Washer | |
| 45 | 5227768 | Adapter | |
| 46 | 5231053 | Accumulator | |
| 47 | 5227894 | Case | |
| 48 | 5227813 | Hose | |
| 49 | 5225149 | Input gear | |
| 50 | 5227788 | Adapter | |
| 51 | 5190318 | Adapter | |
| 52 | 5225146 | Input shaft | |
| 53 | 5651123 | Clutch | |
| 54 | 5651124 | Clutch | |
| 55 | 5675224 | Clutch | |
| 56 | 5219951 | Bearing | |
| 57 | 5243210 | Retainer | |
| 58 | 5225165 | Plate | |
| 59 | 5219948 | Plug | |
| 60 | 5227895 | Case | |
| 61 | 5225166 | Sleeve | |
| 62 | 5219949 | Bearing | |
| 63 | 5216757 | Bearing | |
| 64 | 5219964 | Retainer | |
| 65 | 5225163 | Seal | |
| 66 | 5227909 | Inlet oil cover ring | |
| 67 | 5216763 | O ring | |
| 68 | 5227907 | Inlet oil cover | |
| 69 | 5197592 | Plug | |
| 70 | 5227906 | Inlet oil cover | |
| 71 | 5225168 | Input shaft cover | |
| 72 | 5227908 | Inlet oil cover | |
| 73 | 5216776 | O ring | |
| 74 | 5227905 | Operation valve | |
| 75 | 5225171 | Shifting valve | |
| 76 | 5225173 | Screw | |
| 77 | 5201346 | Wire | |
| 78 | 5216755 | Steel ball | |
| 79 | 5225142 | Spring | |
| 80 | 5243212 | Pin | |
| 81 | 5225175 | Washer | |
| 82 | 5225174 | Plug | |
| 83 | 5216766 | O ring | |
| 84 | 5188750 | O ring | |
| 85 | 5227916 | Flange | |
| 86 | 5238422 | Brand | |
| 87 | 5197590 | Pin | |
| 88 | 5182308 | Bolt | |
| 89 | 5189731 | Washer | |
| 90 | 5188188 | Plugb | |
| 91 | 5219950 | Bearing | |
| 92 | 5227787 | Adapter | |
| 93 | 5227822 | Connection fitting | |
| 94 | 5225172 | Operation stick | |
| 95 | 5221994 | Elbow | |
| 96 | 5222008 | Support | |
| 97 | 5221995 | Plate | |
| 98 | 5219945 | Pin | |
| 99 | 5243220 | Pin | |
| 100 | 5184409 | Washer | |
| 101 | 5225166 | Adapter | |
| 102 | 5225167 | Adapter | |
| 103 | 5225168 | Bracket | |
| 104 | 5225169 | Sensior | |
| 105 | 5225170 | Adapter | |
| 105 | 5225173 | Bearing | |
| 106 | 5225171 | Returning adapter | |
| 107 | 5225172 | Nut | |
| 109 | 5225174 | Bolt | |
| 110 | 5225175 | Washer | |
| 111 | 5227916 | Flange | |
| 112 | 5225176 | Shaft | |
| 113 | 5238420 | Nut | |
| 114 | 5238421 | Sleeve | |
| 115 | 5238422 | Brand | |
| 116 | 5364193 | Bracket | |
| 117 | 5364189 | Adapter | |
| 118 | 5364190 | Park brake | |
| 119 | 5243213 | Pin | |
| 120 | 5219944 | Shaft | |
| 121 | 5243214 | Cotter pin | |
| 122 | 5182309 | Bolt | |
| 123 | 5211352 | Nut | |
| 124 | 5189744 | Washer | |
| 125 | 5221990 | Yoke | |
| 126 | 5221996 | Pin | |
| 127 | 5182329 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
