Каталог запасных частей к технике: SEM656D. Front Axle Wheel-end Reducer As.
1
3
4
5
6
7
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5188247 | Bolt | |
| 2 | 5243277 | Bolt | |
| 3 | 5243269 | Bolt | |
| 4 | 5181821 | Bolt | |
| 5 | 5243285 | Nut | |
| 6 | 5189729 | Washer | |
| 7 | 5189732 | Wahser | |
| 9 | 5184421 | Washer | |
| 10 | 5243203 | Washer | |
| 11 | 5168188 | Plug | |
| 12 | 5188189 | Plug | |
| 13 | 5367898 | Bearing | |
| 14 | 5219961 | Taper roller bearing | |
| 15 | 5219967 | Round steel | |
| 16 | 5383077 | O ring | |
| 17 | 5217526 | Seal-lip type | |
| 18 | 5228162 | Gear-ring | |
| 19 | 5228163 | Planet gear | |
| 20 | 5228164 | Planet gear shaft | |
| 21 | 5228165 | Stell ring | |
| 22 | 5228166 | Needlepoint | |
| 23 | 5228167 | Connecting sleeve | |
| 24 | 5228168 | Screw | |
| 25 | 5183485 | Stop block | |
| 26 | 5183486 | Adjusting column | |
| 27 | 5228169 | Sun gear | |
| 28 | 5228170 | Small hexagon head reaming bolt | |
| 29 | 5228171 | Ring | |
| 30 | 5228172 | Axle | |
| 31 | 5183487 | Adjusting column | |
| 32 | 5183488 | Adjusting column | |
| 33 | 5183489 | Adjusting column | |
| 34 | 5217935 | Adjusting shim | |
| 35 | 5217936 | Adjusting shim | |
| 36 | 5217938 | Adjusting shim | |
| 37 | 5217943 | Adjusting shim | |
| 38 | 5217950 | Adjusting shim | |
| 39 | 5217951 | Double thread stud | |
| 40 | 5217952 | Socket nut | |
| 41 | 5217953 | Lock ring | |
| 42 | 5217954 | Planet gear washer | |
| 43 | 5221868 | Planet gear carrier | |
| 44 | 5221871 | Lid | |
| 45 | 5221872 | Sleeve pipe | |
| 46 | 5221873 | Gear ring carrier | |
| 47 | 5221875 | Retainer-seal | |
| 48 | 5221883 | Hub | |
| 49 | 5221884 | Brake disc | |
| 50 | 5221885 | Sleeve pipe gasket | |
| 51 | 5221886 | Dust boot |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
