Каталог запасных частей к технике: SEM656D. EEF Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5202594 | Bolt | |
| 2 | 5184411 | Washer | |
| 3 | 5189595 | Bolt | |
| 4 | 51844C9 | Washer | |
| 5 | 4314609 | Upper hinge pin fixed tray | |
| 6 | 4314596 | Washer | |
| 7 | 4314597 | Washer | |
| 8 | 4314598 | Adjusting shim | |
| 9 | 5230047 | Upper isolation sleeve | |
| 10 | 5230046 | Down isolation sleeve | |
| 11 | 4314608 | Upper hinge pin | |
| 12 | 5216339 | Fasten plate | |
| 13 | 5182318 | Bolt | |
| 14 | 5182317 | Bolt | |
| 15 | 5177867 | Masher | |
| 16 | 4314613 | Oil cup | |
| 17 | 5230028 | Steering cylinder rear pin | |
| 18 | 5228368 | Washer | |
| 19 | 4693138 | Hinge sleeve adapter | |
| 20 | 5230026 | Lower hinge pin as | |
| 21 | 5177864 | Washer | |
| 22 | 5182325 | Bolt | |
| 23 | 5182328 | Bolt | |
| 24 | 5383111 | Wither | |
| 25 | 5230037 | Rocker pin as. | |
| 26 | 5230035 | Pin lubricating tube | |
| 27 | 5181824 | Bolt | |
| 28 | 5184426 | Combined seal washer | |
| 29 | 5233679 | Adjusting washer | |
| 30 | 5233681 | Adjusting washer | |
| 31 | 5233682 | Adjusting washer | |
| 32 | 5230040 | Rocker rear pin hose | |
| 33 | 5216333 | Rear frame |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
