Каталог запасных частей к технике: SEM655D. Implement hydraulic system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
7
8
9
10
11
11
12
13
14
14
14
14
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
29
30
31
32
33
33
34
35
36
37
38
39
40
41
42
43
44
45
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
201
202
203
204
205
206
207
208
209
210
211
212
213
214
Позиция на иллюстрации Заводской номер детали Название детали
B040811080 B040811080 Bolt
1 Z520520620 Lift cylinder small chamber joint tube
2 Z5205226200 Upper clip
3 Z5205226300 Lower clip
4 Z520521460 Left lift cylinder connnection pipe
5 Z520522610 Clip
6 Z610200080 Split flange
7 NZ5B2000150020 High pressure hose assembly
7 NZ5B2000150010 High pressure hose assembly
8 B050330807 Nut
9 B040910825 Bolt
10 B060460802 Washer
11 NZ5B2000130020 High pressure hose assembly
11 NZ5B2000130010 High pressure hose assembly
12 Z52281001 Implement vlave big chamber joint tube
13 B040911030 Bolt
14 B040911235 Bolt
14 B040911240 Bolt
14 B040911235 Bolt
15 Z520522500 Clip
16 Z520522490 Clip i
17 B050211008 Locknut
18 Z520522600 Clip
19 B040910625 Bolt
20 B050330605 Nut
21 B060460602 Washer
22 Z5B019015 U bolt
23 Z5301905900 Split flange
24 W152200000 Pressure tap
25 B060331003 Washer
26 Z5B019011 Tube bracket
27 B060461203 Washer
29 Z52280023 Implement pump suction fitting
30 B190120800 Clip
31 B160130475 O-ring
32 Z52280025 Lower pressure hose
33 B050331211 Nut
33 B050331211 Nut
34 B100111235 Stud
35 B040911235 Bolt
36 Z5A20202700 Gasket
37 W067400000B Gear pump
38 Z520520920 Connetion fitting
39 B060461002 Washer
40 B160130300 O-ring
41 Z5A20001600 Connection fitting
42 B160120112 O- ring
43 B160130329 O-ring
44 B040820028 Bolt
45 Z52281010 Implement pump oil output pipe as
45 Z52281010 High pressure hose assembly
46 Z520180060 Split flange
47 B190120800 Clip
48 Z52281009 Tube assembly
49 Z610200090 Split flange
50 Z5A20001900 Implement valve pipe
51 Z52281003 High pressure hose assembly
52 Z520520490 Bolt
53 Z5205229100 Clip
54 Z520520670 Connnection pipe
55 Z520190070 Clip
56 B060461002 Washer
57 B160130335 O- ring
58 B150101000 Oil cup
59 Z52281007 Implement valve pipe
60 Z5B01900900 U bolt
61 Z5B01900800 Bracket
62 W058000000 Lifting cylinder
63 B040811065 Bolt
63 B040811070 Bolt
64 Z5B20002100 High pressure hose assembly
65 Z5B20006400 Tilt cylinder big chamber joint tube
66 Z610200080 Split flange
67 W050000000 Tiiting суlinder
68 Z5A20001200 Connnection pipe
69 B050331211 Nut
70 Z5A20004800 Implement valve middle connecting
71 B060331203 Washer
72 W273700000 Implement dispensing valve
73 Z520180060 Split flange
74 B040911225 Bolt
75 Z5B019016 Bracket
76 Z52281005 Implement valve pipe
77 Z520520480 Bolt 142
78 B040911020 Bolt
79 Z52280032 Retaining plate
80 Z520521440 Right lift cylinder connnection pipe
81 Z520520460 Lift cylinder small chamber joint tube
82 W42000297 Plug
82 B160130375 O-ring
82 Z5B068045 High pressure hose assembly
82 W42101000 Oil block assembly
201 W154600150A Fitting
202 Z5A20005900 Iift arm pipe as
203 Z421050670 Pipe clamp
204 B040910820 Bolt
205 Z5A20005600 High pressure hose assembly
206 Z521900710 Pipe adapter
207 Z5A20005400 High pressure hose assemblу
208 Z5A20005200 High pressure hose assembly
209 Z521900690 Pipe adapter
210 Z5A20006100 Lift arm pipe as
211 W273700000 Implement dispensing valve
212 Z5A20004100 Split flange
213 B040911030 Bolt
214 B060461002 Washer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
