Каталог запасных частей к технике: SEM655D. II, IV clutch
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| NZ51021060010 | NZ51021060010 | Clutch component | |
| 1 | B070150001 | Snap ring | |
| 2 | B070158003 | Snap ring | |
| 3 | B070250001 | Snap ring | |
| 4 | B070255002 | Snap ring | |
| 5 | B080210027 | Cotter pin | |
| 6 | B120124018 | Bearing | |
| 7 | B120320001 | Bearing | |
| 8 | B120710500 | Steel ball | |
| 9 | Z510210090 | Gear | |
| 10 | Z510210100 | Clutch shaft | |
| 11 | Z510210250 | Gasket | |
| 12 | Z510210310 | Seal ring | |
| 13 | Z510210390 | Clamping plate | |
| 14 | Z510210400 | Nut | |
| 15 | Z510210440 | Piston | |
| 16 | Z510210450 | Piston outer seal ring | |
| 17 | Z510210470 | Clamping plate | |
| 18 | Z510210500 | Spacer | |
| 19 | Z510210520 | Check valve seat | |
| 20 | Z510210560 | Clutch driving disc | |
| 21 | Z51021158 | Spring | |
| 22 | Z51021159 | Spring retainer | |
| 23 | Z51021162 | Gear | |
| 24 | Z51021163 | Gear sleeve | |
| 25 | Z510210460 | Clutch driven disc |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
