Каталог запасных частей к технике: SEM655D. E & E System
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Z3B550007 | Z3B550007 | Connect line group | |
| W46000072 | W46000072 | Wiper brush | |
| W46000071 | W46000071 | Windshield wiper motor | |
| W46000217 | W46000217 | Wiper | |
| W46000071 | W46000071 | Windshield wiper motor | |
| Z3B550006 | Z3B550006 | Operating light connect line group 1 | |
| W110001370 | W110001370 | Clip | |
| MG19013011 | MG19013011 | One-pipe clip | |
| Z52552002 | Z52552002 | Bracket | |
| 1 | Z52552003 | Harness for rear frame | |
| 2 | W370000070A | Sensing plug for temperature | |
| 3 | W46000178 | Backup alarm | |
| 4 | Z320210080 | Battery cable | |
| 5 | Z5A02102200 | Cover for harness | |
| 6 | Z320210091 | Battery harness | |
| 7 | Z520210340 | Battery cable | |
| 8 | W46000044 | Negative boot | |
| 9 | Z320210070 | Battery cable | |
| 10 | Z420210040 | Oil pipe for oil pressure meter | |
| 11 | W46000046 | Connect for engine oil pipe | |
| 12 | W370000070 | Cover | |
| 13 | Z520210330 | Battery cable | |
| 14 | Z5B021010 | Harness on ceiling | |
| 15 | W46000045 | Transition joints | |
| 16 | W46000192 | Press ion selection valve | |
| 17 | W370400000 | Pressure switch for brake indicate | |
| 18 | Z520210320 | Battery cable | |
| 19 | W370000370A | Clip | |
| 20 | Z5B021008 | Harness for front frame | |
| 21 | Z320210020 | Cover for harness | |
| 22 | W46000168 | Monotone horn | |
| 23 | W46000176 | Really | |
| 24 | Z3B550008 | Horn connecting line component | |
| 25 | W46000177 | Front combined lamp | |
| 26 | W370001910B | Front combine lamp | |
| 27 | W46000359 | Gauge panel | |
| 28 | W46000190 | Anti-fog lamp TCMD | |
| 29 | W46000095 | Light | |
| 30 | W370000160B | Fan | |
| 31 | Z3B02100300 | Fan Retaining plate | |
| 32 | W46000090 | Work light | |
| 33 | W46000010 | Battery | |
| 34 | W370000700B | Left rear combined lamp | |
| 35 | W370000710B | Right rear combined lamp | |
| 36 | W110024070 | Main power switch | |
| 37 | W46000058 | Windshield wiper group | |
| 38 | W46000059 | Rear wiper | |
| 39 | Z52554001 | Rear wiper harness | |
| 40 | W370001140B | Scrubber | |
| 41 | Z52554002 | Washer harness |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
