Каталог запасных частей к технике: SEM652B. Working valve control mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| W101000003B | W101000003B | Woring valve control cable | |
| W101000002B | W101000002B | Tilt contro1 rod | |
| W101000001В | W101000001В | Lift control rod | |
| W101000004B | W101000004B | Woring valve control mechanism dust boot | |
| 1 | B040911020 | Bolt | |
| 2 | B040911030 | Bolt | |
| 3 | B040911220 | Bolt | |
| 4 | B040911230 | Bolt | |
| 5 | B050211210 | Nut | |
| 6 | B060331003 | Washer | |
| 7 | B060410802 | Washer | |
| 8 | B060411203 | Washer | |
| 9 | B080210007 | Retainer pin | |
| 10 | B080210422 | Pin | |
| 11 | B080310826 | Pin | |
| 12 | B080311230 | Shaft pin | |
| 13 | W101000000B | Woring valve control mechanism | |
| 13 | W101000100B | Woring valve control mechanism | |
| 14 | Z420090060 | Bend arm | |
| 15 | Z420090070 | Connecting plate | |
| 16 | Z420090080 | Shaft pin | |
| 17 | Z520510060 | Bracket | |
| 18 | Z5A20400500 | Clip | |
| 19 | Z5B05400100 | Hose bracket assembly |
