Каталог запасных частей к технике: SEM652B. Transmissoin hydraulic system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
37
38
39
40
41
42
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B040910825 | Bolt | |
| 2 | B040911016 | Bolt | |
| 3 | B040911020 | Bolt | |
| 4 | B040911030 | Bolt | |
| 5 | B040911230 | Bolt | |
| 6 | B050331211 | Nut | |
| 7 | B060460802 | Washer | |
| 8 | B060461002 | Washer | |
| 9 | B060461203 | Washer | |
| 10 | B100111235 | Stud | |
| 11 | B160120170 | O-ring | |
| 12 | B160130280 | O-ring | |
| 13 | B160130300 | O-ring | |
| 14 | B160130375 | O-ring | |
| 15 | B190120500 | Clip | |
| 16 | W060600000 | Gear pump | |
| 17 | W154200000A | Oil filter | |
| 18 | Z310260050 | Spacer | |
| 19 | Z320170040 | Adapter | |
| 20 | Z330170070 | Hose | |
| 21 | Z3A01801500 | Adaptor | |
| 22 | Z510260250 | Return oil adapter i of converter | |
| 23 | Z510260710 | Hose | |
| 24 | Z520171190 | Сliр | |
| 25 | Z5A01701900 | Clip | |
| 26 | Z5A01702100 | Double clip | |
| 27 | Z5A01703400 | Adapter | |
| 28 | Z5A01703800 | Adapter of gear box | |
| 29 | Z5A01703900 | Return oil adapter of converter | |
| 30 | Z5B06600100 | Hose as. | |
| 31 | Z5B06600300 | Hose as. | |
| 32 | Z5B06600500 | Hose as. | |
| 33 | Z5B06600700 | Hose as. | |
| 34 | Z5B06600900 | Hose as. | |
| 35 | Z5B06601100 | Hose as. | |
| 37 | Z5B06601300 | Adapter as. | |
| 38 | Z5B06601600 | Adapter as. | |
| 39 | Z5B06601900 | Fixed board | |
| 40 | Z5B06602000 | Tube as. | |
| 41 | Z5B06602200 | Inlet adapter | |
| 42 | Z610200100 | Split flange |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
