Каталог запасных частей к технике: SEM652B. Engine hood assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B01020520 | Bolt | |
| 2 | B040910812 | Bolt | |
| 3 | B040910840 | Bolt | |
| 4 | B040911230 | Bolt | |
| 5 | B040911625 | Bolt | |
| 6 | B050330807 | Nut | |
| 7 | B050330807 | Nut | |
| 8 | B050331614 | Nut | |
| 9 | B060311203 | Washer | |
| 10 | B060410501 | Washer | |
| 11 | B060410802 | Washer | |
| 12 | B060411203 | Washer | |
| 13 | B060411603 | Washer | |
| 14 | B080210003 | Pin | |
| 15 | B080210013 | Pin | |
| 16 | B080310826 | Pin | |
| 17 | W110002390 | Lock | |
| 18 | Z5B01201800 | Support rod | |
| 19 | Z5B01202300 | Stop plate | |
| 20 | Z5B01202400 | Stop pi ate | |
| 21 | Z5B01203400 | Front handle assembly | |
| 22 | Engine hood assembly | Engine hood assembly | |
| 23 | Z5B06101500 | Right door assembly | |
| 24 | Z5B06101600 | Left door assembly | |
| 25 | Z5B06101700 | Rear grill | |
| 26 | Z5B06102900 | Lock plate | |
| 27 | Z5B061032 | Rear bracket | |
| 28 | Z5B061034 | Front bracket | |
| 29 | Z5B061038 | Installation Fixed Seat | |
| 30 | Z6B01203800 | Hinge assembly |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
