Каталог запасных частей к технике: SEM652B. Diesel emgine installation
1
2
3
4
5
6
10
11
12
13
14
15
16
17
18
21
22
23
24
25
26
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B040810016 | Bolt | |
| 2 | B040910840 | Bolt | |
| 3 | B040911040 | Bolt | |
| 4 | B041111430 | Bolt | |
| 5 | B050212419 | Nut | |
| 6 | B050330807 | Nut | |
| 10 | B060111404 | Washer | |
| 11 | B060410802 | Washer | |
| 12 | W220000000B | Diesei | |
| 13 | Z530720060 | Fuel return pipe | |
| 14 | Z5501400500 | Fuel pipe | |
| 15 | Z5A01402700 | Bracket | |
| 16 | Z5B01405500 | Fire bracket | |
| 17 | Z5B01406300 | Extinguishing bracket spacer | |
| 18 | Z5B06300100 | vibration reduction | |
| 21 | Z5B06300800 | Front right bracket | |
| 22 | Z5B06301100 | Front left bracket | |
| 23 | Z5B06301400 | Shim | |
| 24 | W212800030A | Rubber elbow hose assembly | |
| 25 | W212800010A | Airfiiter assembly | |
| 26 | W016300010 | Air fiiter eiement | |
| 27 | W212800050A | Muffer gasket | |
| 28 | W010514050 | Air compressor hose | |
| 29 | W212800070A | Muffer | |
| 30 | W212800040A | Muffer inlet hose | |
| 31 | W212800060A | Turbo-charger assembly | |
| 32 | W212800090A | Rubber elbow hose assembly | |
| 33 | W212800080A | Exhaust tail pipe components |
