Каталог запасных частей к технике: SEM652B. Brake system
1
2
3
4
6
7
8
10
11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B040910820 | Bolt | |
| 2 | B040911020 | Bolt | |
| 3 | B040911025 | Bolt | |
| 4 | B040911230 | Bolt | |
| 5 | B040911435 | Bolt | |
| 6 | B041111630 | Bolt | |
| 7 | B050330605 | Nut | |
| 8 | B050331211 | Nut | |
| 9 | B050331412 | Nut | |
| 10 | B060110802 | Lock washer | |
| 11 | B060111003 | Lock washer | |
| 12 | B060111203 | Lock washer | |
| 13 | B060111404 | Washer | |
| 14 | B060111604 | Washer | |
| 15 | B060410602 | Washer | |
| 16 | W062100000 | Air pressure booster | |
| 17 | W084600000 | Handle brake | |
| 18 | W083300000B | Brake control | |
| 19 | W110000100 | Air brake valve | |
| 20 | W110000160 | Fuel water separator valve | |
| 21 | Z310340020 | Separator Fitting | |
| 22 | Z310530100 | U bolt | |
| 23 | Z320220020 | Fitting | |
| 24 | Z5A02201500 | Brake hose | |
| 25 | Z3212702100 | T-connection fitting | |
| 26 | Z3A02200400 | Brake hose | |
| 27 | Z510100680 | Brake pipe | |
| 28 | Z510100760 | Brake hose | |
| 29 | Z510100810 | Air compressor outlet hose | |
| 30 | Z520220130 | Brake hose | |
| 31 | Z520220220 | Brake hose | |
| 32 | Z520220230 | Brake pipe | |
| 33 | Z520220490 | Bracket | |
| 34 | Z520220860 | Air reservoir aasembly | |
| 35 | Z5A02201100 | Air alarm “t” connector | |
| 36 | Z5B07100100 | Brake hose | |
| 37 | Z5B07100200 | Brake hose | |
| 38 | Z5202209800 | Brake hose | |
| 39 | Z5B07100500 | Brake hose | |
| 40 | Z5B07100800 | Brake hose | |
| 41 | Z5B07100900 | Brake hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
