Каталог запасных частей к технике: SEM652B. Air conditioning system
1
2
3
4
5
6
7
8
9
11
13
14
15
16
17
18
18
18
19
22
23
24
25
26
27
28
28
29
31
31
32
33
34
35
36
37
38
38
39
41
42
43
44
45
46
47
48
49
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Z5B07600000 | Z5B07600000 | Air conditioning system assemblу | |
| 1 | B040810010 | Bolt | |
| 2 | B040811255 | Bolt | |
| 3 | B040910612 | Bolt | |
| 4 | B040910616 | Bolt | |
| 5 | B040910812 | Bolt | |
| 6 | B040910822 | Bolt | |
| 7 | B040911025 | Bolt | |
| 8 | B040911035 | Bolt | |
| 9 | B040911045 | Bolt | |
| 10 | B050330605 | Nut | |
| 11 | B050330807 | Nut | |
| 12 | B050331008 | Nut | |
| 13 | B050331211 | Nut | |
| 14 | B060310601 | Washer | |
| 15 | B060331003 | Washer | |
| 16 | B060410602 | Washer | |
| 17 | B060410802 | Washer | |
| 18 | B060411002 | Washer | |
| 19 | B060411203 | Washer | |
| 20 | B190110500 | Hose clamp | |
| 21 | B190120250 | Hose clamp | |
| 22 | W110001370 | Clip | |
| 23 | W150000030 | Clip | |
| 24 | W300300020A | Hose | |
| 25 | W300400010B | Condenser | |
| 26 | W300900400B | Wiring harness | |
| 27 | W370400140A | Defrosting louver | |
| 28 | W301000300B | Inner defrosting | |
| 29 | W301000100B | Coupler | |
| 30 | W370400110A | Outer defrosting tube | |
| 31 | W370400010A | Evaporator | |
| 32 | W370400100A | Tube bracket | |
| 33 | W370000080B | Compressor to condition tube | |
| 34 | W370000200B | Evaporator to compressor tube | |
| 35 | W370000100B | Warm tube | |
| 36 | W370000110B | Cool tube | |
| 37 | W370400030A | Compressor | |
| 38 | W370000130B | Compressor belt | |
| 39 | W370000140B | Manul water valve | |
| 40 | Z3A02700700 | Clip | |
| 41 | Z520180870 | Clip | |
| 42 | Z5A02700600 | Coupler cover | |
| 43 | Z5A02700700 | Inlet coupler | |
| 44 | Z5B02700100 | Compressor bracket | |
| 45 | Z5B02700400 | Compressor plate | |
| 46 | Z5B02700500 | Compressor joint | |
| 47 | Z5B02700600 | Compressor adjusting bolt | |
| 48 | Z5B02700700 | Coupling | |
| 49 | Z5B07600300 | Bracket beam | |
| 50 | Z5B07600600 | Bracket | |
| 51 | Z5B07600700 | Bracket |
