Каталог запасных частей к технике: SEM650B. TRANSMISSION SYSTEM
1
2
3
4
5
6
7
8
8
9
10
11
12
12
13
14
15
16
17
18
19
19
20
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | NZ62059001010 | Front driving axle assembly | |
| 2 | Z520100040 | Front driving shaft | |
| 3 | W040300000 | Driving shaft bracket | |
| 4 | Z5B366100 | Middle driving shaft | |
| 5 | NZ52010000040 | Gear box | |
| 6 | Z520100020 | Main driving shaft | |
| 7 | W021800000B | Torque converter | |
| 8 | W110000040 | Tire | |
| 8 | W110000250 | Tire | |
| 9 | Z510180010 | Rim assembly | |
| 10 | NZ62059002000 | Rear driving axle assembly | |
| 11 | B050411412 | Nut | |
| 12 | B060111404 | Washer | |
| 13 | Z420100040 | Bolt of main driving shaft | |
| 14 | B041111435 | Bolt | |
| 15 | Z520100010 | Rear output connecting flange | |
| 16 | B060112005 | Washer | |
| 17 | B040912050 | Bolt | |
| 18 | Z420100060 | Stud bolt | |
| 19 | B050411614 | Nut | |
| 20 | B060111604 | Washer | |
| 21 | Z420100050 | Bolt | |
| 22 | Z520030890 | Left bracket gear box | |
| 23 | Z520030640 | Right bracket gear box | |
| 24 | B040912060 | Bolt | |
| 25 | B050332018 | Nut | |
| 26 | Z5A01001700 | Oil hose assembly | |
| 27 | B160130375 | O-ring | |
| 28 | B040911035 | Bolt | |
| 29 | Z5A01002000 | Oil cap | |
| 30 | Z520100030 | Rear driving shaft |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
