Каталог запасных частей к технике: SEM639C. Electrical system

Тип техники

Марка

Модель

Схема

Z3A02100100

W46000071

W46000072

Позиция на иллюстрации	Заводской номер детали	Название детали
Z3A02100100	Z3A02100100	Front frame harness
W46000071	W46000071	Windshield wiper motor
W46000072	W46000072	Wiper brush
1	W370000470A	Anti-fog lamp
2	W370000020A	Ceiling lamp
3	Z5A02103100	Harness on ceiling
4	Z3B02100300	Fan Retaining plate
5	W370000160B	Fan
6	W370000480A	Rear lamp
7	W370001910B	Front combine lamp
8	W46001003	Gauge panel
9	W46000058	Windshield wiper group
10	W110022050	Horn
11	W370001900B	Front lamp
12	Z320210020	Cover for harness
13	W370000260B	Pressure switch
14	W370400000	Pressure switch for brake indicate
15	W370000370A	Clip
16	Z520210320	Battery cable
17	W370000070A	Sensing plug for temperature
18	W110022970	Rear lamp switch
19	Z3B561001	Harness for rear frame
20	W110009610	DC contactor
21	Z330210060	safety Cable
22	W110001370	Clip
23	W370000070	Cover
24	Z320210061	Battery connect cable
25	W46000036	Oil indicator
26	Z3A02101800	Battery cable
27	Z3A02101700	Battery negative cable
28	Z3B021004	Battery connect cable
29	W110025560	Disconnected switch
30	W46000094	Battery
31	W110024070	Main power switch
32	W46000044	Negative boot
33	W370000770B	Backup alarm
34	W370000780B	Rear combine lamp
35	Z5A02102200	Cover for harness
36	W370000790B	Rear combine lamp
37	Z3B561002	Engine water temperature sensor Connection fitting

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
