Каталог запасных частей к технике: SEM639C. Diesel device
W213500000A
W010250080
W010250080
W213800003A
W213800002A
W213800001A
1
2
3
4
5
6
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
20
20
21
21
24
24
25
25
26
26
27
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| W213500000A | W213500000A | Diesel | |
| W010250080 | W010250080 | Filter | |
| W213800003A | W213800003A | Pipe | |
| W213800002A | W213800002A | Muffer | |
| W213800001A | W213800001A | Muffer | |
| 1 | W210420000A | Fan | |
| 2 | Z5A60400800 | Hose | |
| 3 | Z3A60103300 | Hose | |
| 4 | Z3A60101000 | Hose | |
| 5 | Z5A60400700 | Hose | |
| 6 | Z3A60101100 | Hose | |
| 7 | W213800000A | Muffer | |
| 8 | W47031000 | Air filter | |
| 9 | Z3A60100600 | Pipe | |
| 10 | Z5B604049 | Pipe | |
| 11 | Z3B602006 | Bracket | |
| 12 | Z5A60401300 | Fitting | |
| 13 | Z310340020 | Separator Fitting | |
| 14 | Z3B602001 | Transition case | |
| 15 | Z3B602003 | Right front Bracket | |
| 16 | Z3B602002 | Left front Bracket | |
| 17 | Z3A60102900 | Shock absorber | |
| 18 | B050212017 | Locknut | |
| 20 | B040810037 | Bolt | |
| 21 | Z3B602012 | Hose | |
| 24 | Z3A60101600 | Hose | |
| 25 | Z320820020 | Hose | |
| 26 | Z3B602004 | Right front Bracket | |
| 27 | Z3B602005 | Left rear Bracket |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
