Каталог запасных частей к технике: SEM639B. Working device hydraulic system Z3B20000000

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Z3B20000000
1
2
3
4
4
5
6
6
7
7
8
9
9
10
11
12
13
14
15
15
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
40
41
42
42
42
42
43
44
45
45
46
47
47
48
49
50
51
52
52
53
54
55
56
57
58
59
60
61
62
63
64
Позиция на иллюстрации Заводской номер детали Название детали
B050330807 B050330807 Nut
B040810855 B040810855 Bolt
B040910830 B040910830 Bole
B040910825 B040910825 Bolt
B040811080 B040811080 Bolt
B040811065 B040811065 Bolt
B040911030 B040911030 Bolt
B040911025 B040911025 Bolt
B040911020 B040911020 Bolt
B050331008 B050331008 Nut
B060460802 B060460802 Washer
B060330802 B060330802 Washer
B060330802 B060330802 Washer
B060461002 B060461002 Washer
B040811255 B040811255 Bolt
Z3B20000000 Z3B20000000 Working device hydraulic system
1 Z3B20004300 Oil input connector
2 W42000297 Plug
3 Z5B019017 Pressure hose assembly
4 W150000290A Split flange
4 B160130560 O-ring
5 B040911235 Bolt
6 Z520180060 Split flange
6 B010410825 Screw
7 W42101000 Oil block assembly
7 B160130375 O-ring
8 W066900000B Implement cylinder
9 Z3B20010300 Pump Joint plate
9 Z5A20202700 Gasket
10 Z310260030 Washer
11 Z3B20000100 Oil pump connecting sleeve
12 Z3B20016000 Oil output pipe
13 W270500000B Priority valve
14 W272400000A Fitting
15 B040810010 Bolt
15 B050331211 Nut
15 B060461203 Washer
16 W272200000A Fitting
17 Z5A20101000 Adapter
17 B160120090 O-ring
18 Z3B20020000 Fixing bracket assembly
19 Z3B20003800 Pilot hose
20 Z3B20003500 Hose assembly
21 Z3B20028000 Bracket
22 Z320190080 Lower pressure hose
23 B190120600 Clip
24 Z3B20004600 Implement valve Pipe
25 Z3A20005200 Retaining plate
26 B160130236 O-ring
27 Z3A20006700 Lift cylinderhigh pressure oil pipe
28 Z3B20008800 Right Lift cylinder Pipe
29 Z3B20008700 left Lift cylinder Pipe
30 Z320190040 Pipe clamp
31 Z320190030 Hose clip fixed plate
32 Z3B20025000 U bolt
33 Z320020850 Right Pipe clampbracket
34 Z320020830 left Pipe clampBracket
35 Z3B20008500 Connector
36 Z3B20008200 Connector
37 Z3B20014000 Right Lift cylinder Pipe
38 Z3B20008900 Lift cylinder Pipe
39 W050500002 Lift cylinder
39 B150101000 Oil cup
40 Z3B200330 Connector
41 Z3B20008300 Connector
42 W42055002 Safty valve
42 W42055000 Implement dispensing valve
42 W42055001 Safty valve
42 W42055003 Safty valve
43 Z3B200334 Connector
44 B160130224 O-ring
45 Z610200060 Split flange
45 B160130329 O-ring
46 Z3B20008400 Connector
47 Z310100010 Implement valve Bolt
47 Z310100110 Valve fixing bolt
48 W050400001B Tilt cylinder
49 Z3B20006900 High pressure hoseassembly
50 Z3B20008600 Fitting AS
51 Z3B200327 Oil back joint assembly
52 B160130280 O-ring
52 W152200000 Pressure tap
53 Z3B20007100 High pressure hose ass.
54 Z3B20032400 Retaining plate
55 Z5B01900900 U bolt
56 Z3B200340 Pipe assembly
57 Z3B200343 Pipe AS
58 Z3B200346 High pressure hose as.
59 Z3A20006400 Of implement valve
60 B160130425 O ring
61 Z3B20024000 U bolt
62 Z610200090 Split flange
63 Z610200080 Split flange
64 Z610200100 Split flange
