Каталог запасных частей к технике: SEM639B. Torque converter assembly Z3B040000

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Z3B040000
1
1
1
1
1
2
3
5
6
8
9
10
11
11
11
12
12
13
14
15
16
17
18
20
21
22
27
28
30
31
32
34
35
36
37
37
38
39
40
43
44
44
44
46
47
48
48
48
50
52
53
54
55
56
56
57
59
61
62
63
63
64
65
67
68
70
71
72
74
75
77
77
78
79
Позиция на иллюстрации Заводской номер детали Название детали
Z3B040000 Z3B040000 Torque converter assembly
1 B070213001 Snap ring
2 W021300020B Driven gear
3 B120123016 Bearing
5 B121124016 Bearing
6 B120630620 Lock ring
8 B070156803 Snap ring
9 W020200151 Drive pump shaft
10 W021300030B Drive pump shaft
11 W020700006 Relief valve asy
12 B060111203 Lock washer
13 B040911230 Bolt
14 B070213502 Snap ring
15 B120133521 Bearing
16 W020200171 Driven gear
17 B070159003 Snap ring
18 W020200201 Output shaft
19 B120134023 Bearing
20 W020200241 Seal flange
21 W110001590 Oil seal
22 W020200261 Coupling flang
27 B080210545 Spilt
28 W021300010B Driving gear on drive pump
30 B070150002 Snap ring
31 Z200020280 Seal ring
32 W020200041 Stator boss
34 W020200211 Driving shaft
35 W020100210 Seal ring
36 B120135027 Bearing
37 B070150006 Snap ring
38 W020200161 Driving gear
39 B070214802 Snap ring
40 W020200251 Case
43 B160131281 O ring
44 B060110802 Lock washer
46 B040911035 Bolt
47 B040911020 Bolt
48 B060111003 Lock washer
50 W020700020 Flexibility plank
52 B040911225 Bolt
53 W020200081 Coupling wheel
54 W110002670 Needle roller bearing
55 B070155502 Snap ring
56 B070213802 Snap ring
57 W020700003 Turbine
59 B070256002 Snap ring
61 W020700002 Stator
62 W110012130 O ring
63 W020700010 Impeller assembly
63 W020200021 Impeller
64 B050330807 Nut
65 B040910830 Bole
67 B120126022 Bearing
68 B040911030 Bolt
70 W020700030 Flywheel case
71 B010210615 Bolt
72 B060110602 Lock washer
74 W110016140 Oil seal
75 W020200051 Impeller boss
77 Z321260060 Connector
78 Z310260030 Washer
79 W021200030 Cover
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
