Каталог запасных частей к технике: SEM639B. Electrical system Z3B0210000
Z3B0210000
1
2
2
3
4
5
6
7
8
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
21
21
21
22
23
24
25
26
27
27
27
28
28
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Z3B0210000 | Z3B0210000 | Electrical system | |
| 1 | W110022970 | Rear lamp switch | |
| 2 | W370000780B | Rear combine lamp | |
| 2 | W370000790B | Rear combine lamp | |
| 3 | Z5A02102200 | Cover for harness | |
| 4 | W110025560 | Disconnected switch | |
| 5 | W370000070 | Cover | |
| 6 | W370001910B | Front combine lamp | |
| 7 | W46000044 | Negative boot | |
| 8 | W46000094 | Battery | |
| 8 | Z520210330 | Battery cable | |
| 9 | W46000176 | Really | |
| 9 | W46000168 | Monotone horn | |
| 10 | W46000177 | Front combined lamp | |
| 11 | Z320210020 | Cover for harness | |
| 12 | Z3A02101700 | Battery negative cable | |
| 13 | Z3A02101800 | Battery cable | |
| 14 | Z3B021004 | Battery connect cable | |
| 15 | Z3B021005 | Harness | |
| 16 | Z3B550008 | Horn connecting line component | |
| 17 | Z520210320 | Battery cable | |
| 18 | Z3A02101000 | Wire for starter | |
| 19 | Z3B021006 | Line group | |
| 20 | W370000070A | Sensing plug for temperature | |
| 21 | W46000046 | Connect for engine oil pipe | |
| 21 | W46000146 | Joints | |
| 21 | W46000181 | Dash panel | |
| 21 | Z420210040 | Oil pipe for oil pressure meter | |
| 22 | W370400000 | Pressure switch for brake indicate | |
| 23 | W46000088 | Of low pressure | |
| 24 | W370000770B | Backup alarm | |
| 25 | W370000020A | Ceiling lamp | |
| 26 | W370000160B | Fan | |
| 27 | W46000058 | Windshield wiper group | |
| 27 | W46000071 | Windshield wiper motor | |
| 27 | W46000072 | Wiper brush | |
| 28 | W46000090 | Work light | |
| 28 | Z3B550006 | Operating light connect line group 1 | |
| 28 | Z3B550007 | Connect line group | |
| 29 | W46000190 | Anti-fog lamp TCMD | |
| 30 | Z3B02100300 | Fan Retaining plate | |
| 31 | Z3B021007 | On ceiling |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
