Каталог запасных частей к технике: SEM636D. Tilt cylinder
1
1
1
1
2
2
3
4
5
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | W42323050 | Snap ring 90 | |
| 2 | W42323060 | Joint bearing GE60ES | |
| 3 | W42323040 | Piston rod | |
| 4 | O ring | O ring | |
| 5 | Support ring | Support ring | |
| 6 | W42323020 | Piston | |
| 7 | Combined slide ring | Combined slide ring | |
| 8 | Slot nut | Slot nut | |
| 9 | Split pin | Split pin | |
| 10 | W42323010 | Cylider block | |
| 11 | Bolt | Bolt | |
| 12 | Washer | Washer | |
| 13 | Set plate | Set plate | |
| 14 | O ring | O ring | |
| 15 | Combined bearing | Combined bearing | |
| 16 | Combined slide ring | Combined slide ring | |
| 17 | Seal ring of parker | Seal ring of parker | |
| 18 | Snap ring | Snap ring | |
| 19 | Dust ring | Dust ring | |
| 20 | W42323030 | Guide sleeve | |
| 21 | Bolt M16x45 | Bolt M16x45 | |
| 22 | Washer 16 | Washer 16 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
