Каталог запасных частей к технике: SEM636D. Electrical system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
33
34
35
36
37
38
38
38
39
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | W110022990 | proximity switch | |
| 2 | W46000285 | Light | |
| 3 | W46000168 | Monotone horn | |
| 4 | Z3D554007 | Harness | |
| 5 | Z3D554006 | Harness | |
| 6 | W370400000 | Pressure switch for brake indicate | |
| 7 | W46000428 | Electrical control Box | |
| 8 | W46000295 | Temp. sensor | |
| 9 | W46000193 | Switch of reverse lamp pressure | |
| 10 | W46000408 | Pressure switch | |
| 11 | Z3A02101000 | Wire for starter | |
| 12 | W110025560 | Disconnected switch | |
| 13 | Z3B021004 | Battery connect cable | |
| 14 | W46000094 | Battery | |
| 15 | Z330210060 | safety Cable | |
| 16 | Z3D554003 | Harness | |
| 17 | W46000292 | Alarm | |
| 18 | W46000287 | Rear comb lamp | |
| 19 | Z3D554004 | Harness | |
| 20 | W46000378 | Light | |
| 21 | W46000304 | Pressure switch | |
| 22 | Z3D554001 | Harness | |
| 23 | W46000335 | Relay | |
| 24 | Z3D554005 | Harness | |
| 25 | W46000370 | Radio | |
| 26 | W46000297 | Lock | |
| 27 | Z3D554008 | Harness | |
| 28 | W46000372 | horn | |
| 29 | W46000371 | Antenna | |
| 30 | W46000466 | Accelerator pedal | |
| 30 | Z1D021004 | Support | |
| 31 | W46000298 | Combination switch | |
| 32 | W46000294 | Fan | |
| 33 | W46000417 | Light | |
| 34 | W46000095 | Light | |
| 35 | W46000286 | Front light | |
| 36 | W46000290 | Warining light | |
| 37 | 5039587 | dash board | |
| 38 | W46000058 | Windshield wiper group | |
| 38 | W46000071 | Windshield wiper motor | |
| 38 | W46000072 | Wiper brush | |
| 39 | W46000176 | Really | |
| 40 | Z3D554002 | Harness | |
| 41 | W46000299 | Fuse box |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
