Каталог запасных частей к технике: SEM616B. Torque converter assembly
W020100630
W020100630
W020100630
W020100610
W020100610
1
1
1
2
2
2
2
2
2
2
2
4
4
4
4
5
5
6
6
7
7
9
9
10
10
11
11
11
11
11
11
12
12
13
13
14
14
15
15
15
15
16
16
16
17
17
19
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
28
28
29
29
29
30
30
31
31
32
32
34
34
34
34
35
36
37
38
39
40
41
42
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| W020100630 | W020100630 | Lang cover | |
| W020100610 | W020100610 | Impeller assembly | |
| 1 | W030120100 | Case | |
| 2 | W020700210 | Elastic plate | |
| 4 | W020700110 | Impeller shell | |
| 5 | W030123600 | Paper gasket | |
| 6 | W030120500 | Filler | |
| 7 | W020700150 | Main shaft | |
| 9 | W020700240 | Turbine | |
| 10 | W020700080 | Stator | |
| 11 | W020700070 | Impeller | |
| 12 | W030121200 | Impeller hub | |
| 13 | W030121300 | Gasket | |
| 14 | W020700230 | Housing | |
| 15 | W030121500 | Driven gear | |
| 16 | W030121600 | Washer | |
| 17 | W030121700 | Driving shaft | |
| 19 | W030121900 | Driving gear | |
| 20 | W020700200 | Driving gear | |
| 21 | W020100221 | Sealing ring | |
| 22 | W020700160 | Sleeve | |
| 23 | W030122300 | Sleeve | |
| 24 | W020700050 | ) Stator hub | |
| 25 | Z200020280 | Seal ring | |
| 26 | W030122600 | Pin | |
| 27 | W030122700 | Setting sleeve | |
| 28 | W030122800 | Driving shaft | |
| 29 | W020100620 | Cover | |
| 30 | W030123000 | Safety valve assembly | |
| 31 | W030123100 | Outer valve assembly | |
| 32 | W030123200 | Name plate | |
| 34 | W030123400 | Cover | |
| 35 | W030123500 | Paper gasket | |
| 36 | W030123700 | Gasket | |
| 37 | W030123800 | Gear box | |
| 38 | W030123900 | Adapter | |
| 39 | W030125100 | Hose as. | |
| 40 | W030124100 | Joint case | |
| 41 | W030124200 | Joint plate | |
| 42 | W030124300 | Adapter |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
