Каталог запасных частей к технике: SEM616B. Electrical system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
4
4
4
4
5
5
6
6
6
6
7
8
8
8
8
8
9
9
9
10
11
11
11
11
12
12
12
12
12
13
14
15
15
15
15
16
16
16
16
16
17
17
17
17
17
18
19
20
20
20
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
50
50
50
51
52
53
54
55
56
57
57
Позиция на иллюстрации Заводской номер детали Название детали
1 B010710420 Screw
2 B010710520 Screw
3 B010710610 Screw
4 B010710616 Bolt
5 B040910620 Bolt
6 B040910820 Bolt
7 B040910835 Bolt
8 B040911020 Bolt
9 B050330807 Nut
10 B060110602 Lock washer
11 B060110802 Lock washer
12 B060111003 Lock washer
13 B060410402 Washer
14 B060410501 Washer
15 B060410602 Washer
16 B060410802 Washer
17 B060411002 Washer
18 W110000590 Dome lamp
19 W110000620 Main power switch
20 W110023590 Clip
22 W370000070 Cover
23 W370000070A Sensing plug for temperature
24 W370000160B Fan
25 W370000670B Pipe for engine oil pressure meter
26 W370000700B Left rear combined lamp
27 W370000710B Right rear combined lamp
28 W370001910B Front combine lamp
29 W370400000 Pressure switch for brake indicate
30 W46000044 Negative boot
31 W46000046 Connect for engine oil pipe
32 W46000058 Windshield wiper group
33 W46000090 Work light
34 W46000094 Battery
35 W46000146 Joints
36 W46000168 Monotone horn
37 W46000176 Really
38 W46000177 Front combined lamp
39 W370000770B Backup alarm
40 W46000202 Dash panel
41 W46000190 Anti-fog lamp TCMD
42 W46000192 Press ion selection valve
43 W46000193 Switch of reverse lamp pressure
44 Z110100090 Joints
45 Z1B02100400 Battery negative wire
46 Z1B021010 Ceiling harness
47 Z1B02100500 Battery wire for starter
48 Z1B021008 Rear frame harness
49 Z1B553002 Newfane’s
50 Z320210020 Cover for harness
51 Z320210061 Battery connect cable
52 Z3A02101700 Battery negative cable
53 Z3B550006 Operating light connect line group 1
54 Z3B550008 Horn connecting line component
55 Z520210320 Battery cable
56 Z520210330 Battery cable
57 Z5A02102200 Cover for harness
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
