Каталог запасных частей к технике: SEM616B. Braking system
B060801002
Z1B022025
C12031318
Z110070730
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| B060801002 | B060801002 | Combine seal gasket | |
| Z1B022025 | Z1B022025 | Barometer inlet hose | |
| C12031318 | C12031318 | Iron | |
| Z110070730 | Z110070730 | Hand brake | |
| 1 | B060110802 | Lock washer | |
| 2 | Z1B02200300 | Brake hose | |
| 3 | Z110070291 | Brake pipe | |
| 4 | B041200002 | Bolt | |
| 5 | Z1200700700 | Four-way adapter | |
| 6 | B040910830 | Bole | |
| 7 | Z610070100 | Plug | |
| 8 | Z310340020 | Separator Fitting | |
| 9 | W110000100 | Air brake valve | |
| 10 | Z1200701700 | T-connection fitting | |
| 11 | Z1200701600 | Brake hose | |
| 12 | Z1B02200500 | Rake hose | |
| 13 | Z1200701200 | Braking | |
| 14 | Z110070111 | Empowered braking system | |
| 15 | Z1B022020 | Brake hose assembly | |
| 16 | W110002580 | Unloaded valve | |
| 17 | Z1B022018 | Brake hose assembly | |
| 18 | Z3B02200500 | Brake hose assembly | |
| 19 | Z1B022023 | Brake hose assembly | |
| 20 | Z310530100 | U bolt | |
| 21 | B050330605 | Nut | |
| 22 | Z1B022021 | Air compressor outlet hose | |
| 23 | B060410602 | Washer | |
| 24 | Z1B022019 | Air compressor outlet hose support | |
| 25 | B040910880 | Bolt | |
| 26 | B050330807 | Nut | |
| 27 | B060410802 | Washer | |
| 28 | B040910816 | Bolt | |
| 29 | Z1200702100 | T-connection fitting | |
| 30 | Z510100110 | Empowered braking valve adapter | |
| 31 | W152200000 | Pressure tap | |
| 32 | Z1B02201500 | Four-way adapter | |
| 33 | B060331003 | Washer | |
| 34 | B060111003 | Lock washer | |
| 35 | B040911045 | Bolt | |
| 36 | W083000000B | Air reservoir | |
| 37 | B050331211 | Nut | |
| 38 | Z1B02201200 | Assistor bracket | |
| 39 | B040911230 | Bolt | |
| 40 | B060111203 | Lock washer | |
| 41 | W110002650 | Assistor | |
| 42 | B040911030 | Bolt | |
| 43 | Z1B02200600 | Brake hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
