Каталог запасных частей к технике: SDLG LGB680. REAR FRAME MODULE
1
2
3
4
5
6
7
7
8
9
9
10
10
11
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2626000203 | REAR FRAME | |
| 2 | 2626000205 | PLATE | |
| 3 | 4021000050 | JOINT BEARING GB9163-GE50ES-2RS | |
| 4 | 2626000204 | BEARING COVER | |
| 5 | 4015000025 | Washer | |
| 6 | 4011000048 | BOLT | |
| 7 | 2626000207 | SPACER | |
| 8 | 2626000212 | OSCILLATING FRAME | |
| 9 | 4043000283 | BUSH LGB302-40X30A2 | |
| 10 | 4043000143 | PIN LGB301-40X70RX110-40Cr | |
| 11 | 4043000282 | PIN LGB301-35X55RX95-40Cr | |
| 12 | 4043000285 | PIN LGB301-40X125X235-40Cr | |
| 13 | 4040000001 | WASHER | |
| 14 | 4011000087 | BOLT | |
| 15 | 4040000008 | WASHER LGB001-10 | |
| 16 | 4011000081 | BOLT | |
| 17 | 2626000209 | BUSH | |
| 18 | 2626000210 | BUSH | |
| 19 | 2626000211 | COVER | |
| 20 | 4011000092 | BLOT GB5783-M12x50EpZn-8.8 | |
| 21 | 2626000206 | OIL TUBE | |
| 22 | 2925000030 | SPACER | |
| 23 | 2925000029 | OIL BOLT | |
| 24 | 4011000152 | BOLT | |
| 25 | 2626000208 | OIL TUBE | |
| 26 | 4043000284 | BUSH LGB302-65X68A2 | |
| 27 | 2626000214 | OIL TUBE | |
| 28 | 2626000213 | OIL TUBE | |
| 29 | 2925000031 | PIPE CLIP | |
| 30 | 4030000065 | GREASE NIPPLE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
