Каталог запасных частей к технике: SDLG LG969N. Service brake assembly
1
1
1
1
2
2
3
4
5
6
7
8
8
9
10
10
11
12
13
14
15
16
16
17
18
18
18
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
48
49
49
50
50
51
52
53
53
54
55
55
56
57
57
58
58
59
59
60
60
60
60
61
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4041000709 | JOINT LGB120-01616 | |
| 2 | 4041000578 | PIPE LGB125-004130 | |
| 3 | 4041001565 | Hose assembly | |
| 4 | 4041000766 | Nipple | |
| 5 | 4041000768 | O-RING LGB168-11524 | |
| 6 | 4041001464 | Nipple | |
| 7 | 4030000490 | O-RING | |
| 8 | 4041002318 | Hose assembly | |
| 9 | 4041002249 | Hose assembly | |
| 10 | 4190000147 | Nipple | |
| 11 | 29220015341 | Plate | |
| 12 | 29220015331 | Plate | |
| 13 | 4011000481 | BOLT | |
| 14 | 4120004420 | Brake valve | |
| 15 | 4013000033 | NUT | |
| 16 | 4015000256 | WASHER | |
| 17 | 4011000105 | BOLT | |
| 18 | 4190000141 | Nipple | |
| 19 | 29220018781 | Hose | |
| 20 | 29220007831 | TEE PIPE COUPLING | |
| 21 | 4011000082 | BOLT | |
| 22 | 4013000007 | NUT | |
| 23 | 4015000162 | Washer | |
| 24 | 29220011461 | Rubber mat | |
| 25 | 4120002729 | Accumulator | |
| 26 | 29220010311 | Rubber sleeve | |
| 27 | 29220010271 | Nipple | |
| 28 | 29220013191 | Protecting cover | |
| 29 | 29220013211 | Plate | |
| 30 | 4011000934 | Screw | |
| 31 | 4041000843 | Hose | |
| 32 | 4041001765 | Hose assembly | |
| 33 | 4041001986 | Hose assembly | |
| 34 | 4015000072 | WASHER | |
| 35 | 29220010301 | U-bolt | |
| 36 | 4013000210 | Nut | |
| 37 | 4011000447 | BOLT | |
| 38 | 4041001990 | Hose | |
| 39 | 4011000560 | BOLT | |
| 40 | 29220018201 | Bracket | |
| 41 | 4120004397 | Non-return valve | |
| 42 | 29220009261 | Bolt | |
| 43 | 29220018791 | Hose | |
| 44 | 4011000527 | BOLT | |
| 45 | 29220009221 | Block | |
| 46 | 4120004340 | Switch | |
| 47 | 4041001663 | Hose | |
| 48 | 29220012581 | Nipple | |
| 49 | 4030000894 | O-ring | |
| 50 | 4120004417 | Hydraulic fluid filter | |
| 51 | 29220017621 | Nipple | |
| 52 | 4190000143 | Three-way nipple | |
| 53 | 4190000149 | Nipple | |
| 54 | 4120004417001 | Filter insert | |
| 55 | 29010000031 | Clamp | |
| 56 | 4041001906 | Hose | |
| 57 | 4011000807 | Bolt | |
| 58 | 4011000307 | BOLT GB16674-M10x45EpZn-8.8 | |
| 59 | 29220007891 | CUSHION BLOCK | |
| 60 | 4041000780 | O-RING LGB168-11324 | |
| 61 | 4041000712 | HOSE LGB124-004059 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
