Каталог запасных частей к технике: SDLG LG969N. Engine hood assembly

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
Позиция на иллюстрации Заводской номер детали Название детали
1 29360015191 Emblem
2 29330054801 Bonnet
3 26330006531 Rubber block
4 4015000256 WASHER
5 4013000033 NUT
6 29330033331 Sponge
7 29330033341 Sponge
8 29330035521 Sponge
9 4011000560 BOLT
10 29330038541 Sponge
11 29330038551 Sponge
12 29330033271 Protecting grating
13 29330033571 Wire gauze
14 29330033301 Sponge
15 4130000075 BOLT GB16674-M6x12EpZn-8.8
16 29330038561 Bracket
17 29330033371 Sponge
18 29330033381 Sponge
19 29330011232 RUBBER COVER
20 29330016461 RIGHT UPPER HANDRAIL
21 29330016441 LEFT UPPER HANDRAIL
22 29330033071 Right door plate
23 29330033121 Left door plate
24 29330033351 Sponge
25 29330033361 Sponge
26 29330000081 PNEUMATIC SPRING
27 29330032901 Bonnet support
28 29330033391 Sponge
29 29330033401 Sponge
30 29330000092 FRONT LOCK PLATE
31 29330001531 HINGE
32 4011000447 BOLT
33 29330001541 RUBBER PAD
34 4013000007 NUT
35 29330001511 PAD BLOCK
36 29330033411 Sponge
37 29330033421 Sponge
38 4011000151 BOLT
39 4015000181 WASHER
40 4013000016 NUT
41 4011000477 BOLT
42 4030000535 OIL CUP
43 29330033171 Plate
44 29330033211 Plate
45 29330032951 Bracket
46 29330033431 Pull rod
47 29330033441 Pull rod
48 29330033231 Cover plate
49 29330000171 SHORT LINK
50 29330000181 SHORT LINK
51 29330054481 Door
52 29330054641 Cover
53 29330038591 Sponge
54 29330001891 HANDRAIL
55 29330052841 Shim
56 29330052851 Shim
57 4011000594 Screw
58 29330020211 SPACER
59 29330020221 SPACER
60 29330028191 Attaching sleeve
61 29330033492 Window
62 4190002281 Door lock
63 4011000099 Screw
64 4190002284 Washer
65 4190002283 Catch
66 29330000241 TURN PLATE
67 4015000162 Washer
68 4016000119 PIN
69 4016000114 PIN
70 4015000207 WASHER
71 4090000150 Sealing strip
72 4090000053 Sealing strip
73 4016000035 SPLIT PIN
74 29340009091 LINK ASSEM
75 4015000168 WASHER
76 29330038611 Sponge
