Каталог запасных частей к технике: SDLG LG969. TEERING CYLINDER (371368)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Позиция на иллюстрации Заводской номер детали Название детали
1 4120000602101 PISTON ROD
2 4120000602102 SEALING MEMBER AGGREGATE
3 4120000602102 SEALING MEMBER AGGREGATE
4 4120000602103 CYLINDER COVER
5 4120000602102 SEALING MEMBER AGGREGATE
6 4120000602102 SEALING MEMBER AGGREGATE
7 4120000602102 SEALING MEMBER AGGREGATE
8 4120000602102 SEALING MEMBER AGGREGATE
9 4120000602108 CYLINDER BODY
10 4120000602102 SEALING MEMBER AGGREGATE
11 4120000602102 SEALING MEMBER AGGREGATE
12 4120000602110 PISTON
13 4120000602102 SEALING MEMBER AGGREGATE
14 4014000238 SCREW
15 4015000014 SNAP RING GB893.1-75-65Mn
16 4120000602114 SPHERICAL PLAIN BEARING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
