Каталог запасных частей к технике: SDLG LG968. LIFTING CYLINDER (371368)
/43.gif)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120000558102 | RETAINER HSGF-160/90x812.5-1 | |
| 2 | 4120000600102 | PISTON ROD | |
| 3 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 4 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 5 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 6 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 7 | 4120000600105 | CYLINDER COVER | |
| 8 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 9 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 10 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 11 | 4120000600108 | CYLINDER BODY | |
| 12 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 13 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 14 | 4120000600103 | SEALING MEMBER AGGREGATE | |
| 15 | 4014000239 | SCREW GB70.1-M8x30-8.8 | |
| 16 | 4120000600111 | PISTON | |
| 17 | 4120000600113 | BUSHING | |
| 18 | 4011000865 | BOLT GB5785-M16x1.5x65EpZn-10.9 | |
| 19 | 4015000098 | WASHER GB93-16-65Mn | |
| 20 | 4120000600103 | SEALING MEMBER AGGREGATE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
