Каталог запасных частей к технике: SDLG LG968. ELECTRIC SYSTEM
/72.gif)
1
2
2
2
2
2
3
4
5
6
6
7
8
8
9
10
11
11
12
12
13
13
14
14
15
15
16
16
17
18
18
18
18
18
18
19
20
21
22
23
24
25
25
27
28
29
30
30
31
31
32
33
33
33
33
34
35
35
36
37
37
38
38
39
40
41
42
42
43
43
44
44
44
44
45
45
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 29370009571 | LINE FROM SWITCH TO MOTOR | |
| 2 | 4011000461 | BOLT | |
| 3 | 29370014291 | BATTERY WIRE A50x350 | |
| 4 | 4130000427 | POWER SWITCH K01K18-A | |
| 5 | 29370014261 | BATTERY WIRE P50x150 | |
| 6 | 4130000057 | BATTERY | |
| 7 | 29370013101 | BATTERY CABLE | |
| 8 | 29310011841 | DIP RUBBER BAR | |
| 9 | 29370015301 | RELAY PROTECT BOX | |
| 10 | 4014000024 | SCREW | |
| 11 | 4015000207 | WASHER | |
| 12 | 4015000035 | WASHER | |
| 13 | 4130000694 | CONTACTOR | |
| 14 | 4014000061 | SCREW | |
| 15 | 4015000135 | WASHER | |
| 16 | 4015000033 | WASHER GB93-4-65Mn | |
| 17 | 29370015291 | RELAY FIXATION PLANT | |
| 18 | 4190000020 | CLIP | |
| 19 | 26370001911 | CLAMP | |
| 20 | 4130000009 | ELECTRIC HORN | |
| 21 | 4011000152 | BOLT | |
| 22 | 4130000542 | LEFT FRONT HEAD LAMP | |
| 23 | 29370014021 | FRONT BODY WIRING HARNESS | |
| 24 | 4130000543 | RIGHT FRONT HEAD LAMP | |
| 25 | 4130000329 | PRESS SWITCH | |
| 26 | 29370015591 | FIXED PLATE OF STARTUP RELAY | |
| 27 | 4130000874 | ENABLE RELAY SW030A3509-2 | |
| 28 | 4014000026 | SCREW | |
| 29 | 29370015381 | BODY WIRING HARNESS | |
| 30 | 4130000213 | REAR LAMP | |
| 31 | 4130000544 | REAR LARGE LAMP SPH4-1031 | |
| 32 | 29370009531 | COVER HARNESS | |
| 33 | 4130000615 | FORWARD LIGHTING | |
| 34 | 4130000121 | Buzzer | |
| 35 | 29370015081 | PANEL HARNESS ASSEMBLY | |
| 36 | 4014000048 | SCREW | |
| 37 | 4015000110 | WASHER | |
| 38 | 4015000034 | WASHER GB93-5-65Mn | |
| 39 | 4013000118 | NUT GB6170-M5EpZn-8 | |
| 40 | 4130000869 | Relay | |
| 41 | 29370015341 | PANEL ASSEMBLY Y958CAT | |
| 42 | 29370013341 | PANEL ASSEMBLY | |
| 43 | 4130000498 | SIDE FRAME | |
| 44 | 4130000496 | CAP | |
| 45 | 4130000497 | Switch panel | |
| 46 | 4130000060 | HAND BRAKE SWITCH |
