Каталог запасных частей к технике: SDLG LG958N. Engine hood
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 29360015191 | Emblem | |
| 2 | 29330054801 | Bonnet | |
| 3 | 26330006531 | Rubber block | |
| 4 | 4015000256 | WASHER | |
| 5 | 4013000033 | NUT | |
| 6 | 4011000560 | BOLT | |
| 7 | 29330033271 | Protecting grating | |
| 8 | 29330033571 | Wire gauze | |
| 9 | 4130000075 | BOLT GB16674-M6x12EpZn-8.8 | |
| 10 | 29330038561 | Bracket | |
| 11 | 29330011232 | RUBBER COVER | |
| 12 | 29330016461 | RIGHT UPPER HANDRAIL | |
| 13 | 29330016441 | LEFT UPPER HANDRAIL | |
| 14 | 29330033071 | Right door plate | |
| 15 | 29330033121 | Left door plate | |
| 16 | 29330000081 | PNEUMATIC SPRING | |
| 17 | 29330032901 | Bonnet support | |
| 18 | 29330000092 | FRONT LOCK PLATE | |
| 19 | 29330001531 | HINGE | |
| 20 | 4011000447 | BOLT | |
| 21 | 29330001541 | RUBBER PAD | |
| 22 | 4013000007 | NUT | |
| 23 | 29330001511 | PAD BLOCK | |
| 24 | 4011000151 | BOLT | |
| 25 | 4015000181 | WASHER | |
| 26 | 4013000016 | NUT | |
| 27 | 4011000477 | BOLT | |
| 28 | 4030000535 | OIL CUP | |
| 29 | 29330033171 | Plate | |
| 30 | 29330033211 | Plate | |
| 31 | 29330032951 | Bracket | |
| 32 | 29330033431 | Pull rod | |
| 33 | 29330033441 | Pull rod | |
| 34 | 29330033231 | Cover plate | |
| 35 | 29330000171 | SHORT LINK | |
| 36 | 29330000181 | SHORT LINK | |
| 37 | 29330054481 | Door | |
| 38 | 29330054641 | Cover | |
| 39 | 29330001891 | HANDRAIL | |
| 40 | 29330052841 | Shim | |
| 41 | 29330052851 | Shim | |
| 42 | 4011000594 | Screw | |
| 43 | 29330020211 | SPACER | |
| 44 | 29330020221 | SPACER | |
| 45 | 29330028191 | Attaching sleeve | |
| 46 | 29330033492 | Window | |
| 47 | 4190002281 | Door lock | |
| 48 | 4011000099 | Screw | |
| 49 | 4190002284 | Washer | |
| 50 | 4190002283 | Catch | |
| 51 | 29330000241 | TURN PLATE | |
| 52 | 4015000162 | Washer | |
| 53 | 4016000119 | PIN | |
| 54 | 4016000114 | PIN | |
| 55 | 4015000207 | WASHER | |
| 56 | 4090000150 | Sealing strip | |
| 57 | 4090000053 | Sealing strip | |
| 58 | 4016000035 | SPLIT PIN | |
| 59 | 29340009091 | LINK ASSEM | |
| 60 | 4015000168 | WASHER | |
| 61 | 29330038271 | Engine cover |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
