Каталог запасных частей к технике: SDLG LG958L. TILT CYLINDER (371368)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Позиция на иллюстрации Заводской номер детали Название детали
1 4120002264102 PISTON ROD HSGF-190/100x545-1
2 4120002264101 SEALING MEMBER AGGREGATE
3 4120002264101 SEALING MEMBER AGGREGATE
4 4120002264101 SEALING MEMBER AGGREGATE
5 4120002264101 SEALING MEMBER AGGREGATE
6 4120002264101 SEALING MEMBER AGGREGATE
7 4120002264101 SEALING MEMBER AGGREGATE
8 4120002264103 CYLINDER COVER HSGF-190/100x545-2
9 4120002264104 CYLINDER BODY HSGF-190/100x545-3
10 4120002264101 SEALING MEMBER AGGREGATE
11 4120002264101 SEALING MEMBER AGGREGATE
12 4120002264101 SEALING MEMBER AGGREGATE
13 4120002264105 PISTON HSGF-190/100x545-4
14 4014000239 SCREW GB70.1-M8x30-8.8
15 4030000065 GREASE NIPPLE
16 4120001744109 BUSHING HSGF-180/90x542-5
17 4120001744110 BUSHING HSGF-180/90x542-6
18 4011000791 BOLT GB5785-M18x1.5x70EpZn-10.9
19 4015000029 WASHER
20 4120002264101 SEALING MEMBER AGGREGATE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
