Каталог запасных частей к технике: SDLG LG958L. LIFT ARM CYLINDER (371368)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Позиция на иллюстрации Заводской номер детали Название детали
1 4120002063102 RETAINER HSGF-165/90x767-l
2 4120002063103 PISTON ROD HSGF-180/90x767-l
3 4120002263101 SEALING MEMBER AGGREGATE
4 4120002263101 SEALING MEMBER AGGREGATE
5 4120002263101 SEALING MEMBER AGGREGATE
6 4120002263101 SEALING MEMBER AGGREGATE
7 4120002263104 CYLINDER COVER HSGF-170/90x767-4
8 4120002263101 SEALING MEMBER AGGREGATE
9 4120002263101 SEALING MEMBER AGGREGATE
10 4120002263101 SEALING MEMBER AGGREGATE
11 4120002263105 CYLINDER BODY HSGF-170/90x767-2
12 4120002263101 SEALING MEMBER AGGREGATE
13 4120002263101 SEALING MEMBER AGGREGATE
14 4120002263101 SEALING MEMBER AGGREGATE
15 4014000239 SCREW GB70.1-M8x30-8.8
16 4120002263106 PISTON HSGF-170/90x767-3
17 4120002063107 COMPOUND BUSH JB/T7521-1994
18 4120002263101 SEALING MEMBER AGGREGATE
19 4011000863 BOLT GB5786-M18x1.5x70EpZn-10.9
20 4015000029 WASHER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
