Каталог запасных частей к технике: SDLG LG958L. HOOD OF DIESEL ENGINE ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
Позиция на иллюстрации Заводской номер детали Название детали
1 29330018441 REAR HOOD
2 29330034571 Sponge
3 29330034581 Sponge
4 29330034551 Sponge
5 29330034561 Sponge
6 29330016241 REAR BRACKET
7 29330016401 UP BRACKET
8 4011000447 BOLT
9 4015000197 WASHER
10 4015000162 Washer
11 29330011232 RUBBER COVER
12 29330016441 LEFT UPPER HANDRAIL
13 29330016461 RIGHT UPPER HANDRAIL
14 29330034461 Sponge
15 29330001541 RUBBER PAD
16 29330016481 LEFT SIDE DOOR ASS’Y
17 29330016551 RIGHT SIDE DOOR
18 29330034441 Sponge
19 29330034451 Sponge
20 29330034481 Sponge
21 29330016821 CLIP RUBBER BAR
22 29330016611 FRONT BRACKET
23 29330014621 AIR SPRING
24 29330034501 Sponge
25 4030000750 Sealing strip
26 29330000092 FRONT LOCK PLATE
27 29330001531 HINGE
28 29330016651 RIGHT HOOD
29 29330016631 LEFT HOOD
30 4011000151 BOLT
31 4015000181 WASHER
32 4013000016 NUT
33 4011000477 BOLT
34 4030000535 OIL CUP
35 29330034531 Sponge
36 29330034541 Sponge
37 29330034521 Sponge
38 29330016671 LEFT LONG LINK
39 29330016681 RIGHT LONG LINK
40 4013000007 NUT
41 29330001511 PAD BLOCK
42 29330000171 SHORT LINK
43 29330000181 SHORT LINK
44 4130000075 BOLT GB16674-M6x12EpZn-8.8
45 4190000916 LOCK
46 29330016691 LEFT HALFTONE
47 29330016731 RIGHT HALFTONE
48 29330018691 HALFTONE
49 29330018731 HALFTONE
50 29330000201 RUBBER COVER
51 29330001891 HANDRAIL
52 4011000560 BOLT
53 29330034591 Sponge
54 4011000094 BOLT
55 29330020211 SPACER
56 29330020221 SPACER
57 29330023161 WASHER 16
58 29330019431 WINDOW PILLAR
59 4011000081 BOLT
60 29330000241 TURN PLATE
61 4016000119 PIN
62 4016000114 PIN
63 4015000207 WASHER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
