Каталог запасных частей к технике: SDLG LG958L. PERFORMANCE, PARTS PP40722
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
29
30
30
31
32
33
33
34
35
36
37
38
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4110000081209 | PLUG, PIPE C3008464 | |
| 2 | 4110000081210 | PLUG, PIPE C3008466 | |
| 3 | 4110000081211 | PLUG, PIPE | |
| 4 | 4110000081285 | GEAR,CAMSHAFT C3415430 | |
| 5 | 4110000081242 | GASKET,CYLINDER HEAD C3415501 | |
| 6 | 4110000081188 | SCREW, HEXGON HEAD CAP | |
| 7 | 4110000081141 | ROD, ENGINE CONNECTING C3901383 | |
| 8 | 4110000081142 | BEARING,CONNECTING ROD C3901430 | |
| 9 | 4110000081046 | KEY,PLAIN WOODRUFF C3902332 | |
| 10 | 4110000081203 | SEALING WASHER | |
| 11 | 4110000081228 | SEAL, INJECTOR C3909886 | |
| 12 | 4110000081229 | CLAMP, INJECTOR C3910279 | |
| 13 | 4110000081168 | SCREW, HEX FLANGE HEAD C3917729 | |
| 14 | 4110000081004 | OIL ATOMIZER | |
| 15 | 4110000081333 | RING, COMPRESSION PISTO C3919918 | |
| 16 | 4110000081061 | RING, RETAINING C3920692 | |
| 17 | 4110000081310 | RING,OIL PISTON C3921919 | |
| 18 | 4110000081271 | RING,COMPRESSION PISTO C3922686 | |
| 19 | 4110000081283 | CAMSHAFT C3923478 | |
| 20 | 4110000081099 | PISTON, ENGINE C3923537 | |
| 21 | 4110000081197 | PLUG, THREADED | |
| 22 | 4110000081286 | SUPPORT, CAMSHAFT THRUST | |
| 23 | 4110000081101 | PPN,PISTON C3934046 | |
| 24 | 4110000081176 | SCREW,HEX FLANGE HEAD C3960043 | |
| 25 | 4110000081243 | HEAD, CYLINDER C3991152 | |
| 26 | 4110000081238 | COLLET,VALVE 3901177 | |
| 27 | 4110000081226 | VALVE,EXHAUST 3921444 | |
| 28 | 4110000081118 | VALVE, INTAKE 3924492 | |
| 29 | 4110000081235 | SEAL, VALVE STEM 3927642 | |
| 30 | 4110000081233 | RETAINER, VALVE SPRING C3912976 | |
| 31 | 4110000081241 | HEAD, CYLINDER C3936180 | |
| 32 | 4110000081239 | INSERT,VALVE 3908830 | |
| 33 | 4110000081234 | GUIDE,VALVE STEM 3925863 | |
| 34 | 4110000081240 | INSERT,VALVE 3928174 | |
| 35 | 4110000081296 | PLUG, EXPANSION | |
| 36 | 4110000081299 | PLUG,EXPANSION C3914035 | |
| 37 | 4110000081300 | PLUG,EXPANSION C3920443 | |
| 38 | 4110000081119 | SPRING, VALVE C3991085 | |
| 39 | 4110000081184 | SCREW,HEX FLANGE HEAD Q1840880 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
