Каталог запасных частей к технике: SDLG LG958L. HYDRAULIC CONTROL ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
3
3
3
3
3
3
4
4
4
4
4
5
5
5
5
5
6
7
8
9
9
10
10
10
10
10
10
10
10
10
10
11
12
13
14
15
15
15
15
15
15
16
16
16
16
17
17
17
17
18
19
19
20
20
21
22
23
24
24
25
25
25
26
27
27
28
29
30
31
32
33
34
35
36
37
37
37
37
37
37
38
39
39
40
41
42
43
44
44
44
45
45
45
46
47
48
49
50
51
52
53
54
54
55
55
56
57
58
59
60
61
62
63
64
65
65
66
66
67
67
68
69
70
71
72
73
74
76
77
78
79
80
81
82
83
84
85
Позиция на иллюстрации Заводской номер детали Название детали
1 4041000604 JOINT
2 29120016561 OIL PIPE
3 4041000767 O-RING
4 4015000168 WASHER
5 4013000011 NUT
6 4011000057 BOLT
7 4011000056 BOLT
8 4120002304 Control valve
9 29120007651 JOINT
10 29120014931 WASHER
11 29120016551 FRONT PILOT PIPE
12 29120016251 CLAMPING PLATE OF CONTROL VALVE
13 4011000149 BOLT GB16674-M16x50EpZn-8.8
14 29120000031 OIL OUTLET TUBE OF OIL INLET TUBE
15 4011000477 BOLT
16 4041000011 FLANGE
17 4030000130 O-RING
18 29120000051 FTEADY REST 1
19 4041000954 U-BOLT LGB159-14254
20 4041000955 BOTTOM SHEET LGB160-4254
21 4041001263 PIPE LGB161-414118
22 4041001254 HOSE LGB106-013126
23 4041000056 FLANGE
24 4030000029 O-RING
25 4011000475 BOLT
26 29120014731 RENTURN PIPE
27 4041000632 PIPE
28 4011000473 BOLT
29 4120000448 PRESSURE SELECTION VALVE
30 29120016261 HOSE
31 4041000095 CONNECTER
32 4041000768 O-RING LGB168-11524
33 29120015911 COVER PS
34 4014000058 SCREW
35 4011000488 BOLT
36 4120002027 PILOT VALVE
37 29120015401 FITTING
38 29120010831 FRONT PILOT PTPE
39 4011000344 BOLT
40 29120016101 OIL RETURN PIPE OF PUMP
41 4011000366 BOLT
42 29120015221 WASHER
43 29120016901 MOUNTED PLATE
44 4011000447 BOLT
45 4041000774 PLUG
46 29120012111 TRANSITION BLOCK
47 4011000279 BOLT GB16674-M10x60EpZn-8.8
48 4041000143 STAIGHT JOINT LGB120-02222
49 4041000771 O-RING
50 4011000461 BOLT
51 29120007671 CLAMP
52 4041001023 JOINT
53 4030000240 O-RING
54 29120015081 JOINT
55 4030000276 O-RING
56 4120001954 STRAINER
57 29120016021 PLATE
58 29120007561 OIL RETURN PIPE OF SELECTION VALVE
59 4041000150 STAIGHT JOINT
60 4011000560 BOLT
61 29120016951 MOUNTED PLATE
62 29120016741 CLAMP
63 29120016351 MOUNTED PLATE
64 4011000493 BOLT
65 4041000716 DUST-PREVENTION CAP
66 4041000027 FLANGE
67 29120016141 FIXED BEARER
68 29120016571 PIPE
69 29120016581 PIPE
70 29120016121 FEEDING STEEL TUBE OF MULTIPLE UNIT VALVE
71 4041001047 CONNECTOR
72 4030000530 O-RING
73 4041001223 HOSE LGB125-003060
74 29120014012 FRONT CAP
75 4011000081 BOLT
76 4015000197 WASHER
77 29120016591 PIPE
78 29120016601 PIPE
79 4041000708 BLOCKING
80 4030000504 O-RING GB3452.1-25.8x1.80G
81 4190000020 CLIP
82 29120015751 THREE-WAY PIPE
83 4011000560 BOLT
84 4041000192 PLUG
85 4041000765 O-RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
