Каталог запасных частей к технике: SDLG LG956L. Steering cylinder

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
6
7
8
8
9
10
11
11
12
13
14
15
16
17
17
18
Позиция на иллюстрации Заводской номер детали Название детали
1 4120000553102 PISTON ROD HSGL-90/50x424-1
2 4030000065 GREASE NIPPLE
3 4120000553101 SEALING MEMBER AGGREGATE
4 4120000553101 SEALING MEMBER AGGREGATE
5 4120000553101 SEALING MEMBER AGGREGATE
6 4120000553101 SEALING MEMBER AGGREGATE
7 4120000553107 CYLINDER COVER HSGL-90/50x424-3
8 4120000553101 SEALING MEMBER AGGREGATE
9 4120000553109 CYLINDER BODY HSGL-90/50x424-4
10 4120000553101 SEALING MEMBER AGGREGATE
11 4120000553101 SEALING MEMBER AGGREGATE
12 4120000553101 SEALING MEMBER AGGREGATE
13 4014000237 SCREW
14 4120000553114 PISTON HSGL-90/50x424-5
15 4021000050 JOINT BEARING GB9163-GE50ES-2RS
16 4015000014 SNAP RING GB893.1-75-65Mn
17 4120000553115 BUSHING HSGL-90/50x424-2
18 4120000553101 SEALING MEMBER AGGREGATE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
