Каталог запасных частей к технике: SDLG LG956FH. Hydraulic control system
1
2
3
4
4
4
4
4
5
6
6
6
6
7
7
7
7
8
8
9
10
10
11
12
12
13
13
14
15
15
16
17
17
18
19
20
21
22
22
22
22
23
24
25
26
27
28
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 29120029501 | Control lever assembly | |
| 2 | 29120031281 | Hydraulic control | |
| 3 | 29120029491 | Control valve assembly | |
| 4 | 4041000767 | O-RING | |
| 5 | 4041000604 | JOINT | |
| 6 | 4041001023 | JOINT | |
| 7 | 4030000240 | O-RING | |
| 8 | 4041002606 | Hose assembly | |
| 9 | 4011001238 | Screw | |
| 10 | 4015000433 | Washer | |
| 11 | 29120029541 | Plate | |
| 12 | 29120015081 | JOINT | |
| 13 | 4030000276 | O-RING | |
| 14 | 4041000602 | Hose | |
| 15 | 29120014931 | WASHER | |
| 16 | 29120007661 | Nipple | |
| 17 | 4041001552 | Hose assembly | |
| 18 | 4120005063 | Valve | |
| 19 | 4011001262 | Bolt | |
| 20 | 4041000766 | Nipple | |
| 21 | 4041000768 | O-RING LGB168-11524 | |
| 22 | 4041000774 | PLUG | |
| 23 | 29120007651 | JOINT | |
| 24 | 4120001100 | Three-way nipple | |
| 25 | 4041002789 | Hose assembly | |
| 26 | 4190000056 | Cable tie | |
| 27 | 4190001832 | Cable tie | |
| 28 | 4041001537 | Hose assembly | |
| 29 | 4120001954 | STRAINER | |
| 30 | 4041000777 | THREAD PLUG LGB135-02227 | |
| 31 | 4041000771 | O-RING | |
| 32 | 4041002417 | Clamp | |
| 33 | 4120001954001 | Filter insert |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
