Каталог запасных частей к технике: SDLG LG956F. Cab accessories
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4011001285 | Screw | |
| 2 | 4015000437 | Washer | |
| 3 | 29350010471 | Ventilation unit | |
| 4 | 29310016951 | Spacer plate | |
| 5 | 4011001296 | Screw | |
| 6 | 4011001247 | Screw | |
| 7 | 4015000425 | Washer | |
| 8 | 29310025851 | Plate | |
| 9 | 4011001432 | Bolt | |
| 10 | 4011000915 | BOLT GB5783-M30x2x140-8.8 | |
| 11 | 4110000453 | SHOCK ABSORBER CB124 | |
| 12 | 4015000119 | WASHER | |
| 13 | 4013000064 | LOCKING NUT | |
| 14 | 29310024461 | Washer | |
| 15 | 29310025881 | Plate | |
| 16 | 29310025841 | Floor mat | |
| 17 | 29310018251 | Rubber cap | |
| 18 | 29310024811 | Plate | |
| 19 | 4043001246 | Sealing strip | |
| 20 | 29310025871 | Plate | |
| 21 | 29310025831 | Floor mat | |
| 22 | 26310001872 | Rubber sleeve | |
| 23 | 4190000019 | Cable tie | |
| 24 | 29290012861 | Air outlet | |
| 25 | 29310019001 | Protecting cover | |
| 26 | 29310012601 | COVER 32 | |
| 27 | 29290014041 | Grommet | |
| 28 | 29310018991 | Rubber sleeve | |
| 29 | 29310020381 | Plastic rivet | |
| 30 | 4014000535 | Screw | |
| 31 | 29310018981 | Protecting cover | |
| 32 | 29310016411 | Protecting cover | |
| 33 | 29290012851 | Air outlet | |
| 34 | 29290012561 | Protecting cover | |
| 35 | 4014000522 | Screw | |
| 36 | 26290004591 | Nut | |
| 37 | 29310016431 | Cover plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
