Каталог запасных частей к технике: SDLG LG956. SERVICE BRAKE SYSTEM

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
11
11
11
12
13
14
15
15
16
17
18
19
19
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
Позиция на иллюстрации Заводской номер детали Название детали
1 2922000002 WASHER
2 2922000003 CONNECTOR
3 2922000004 TUBE OF REAR AXLE
4 2922000057 TUBE TO FRONT AXLE
5 4011000461 BOLT
6 2901000003 CLIP
7 2922000010 CONNECTORS
8 4011000479 BOLT
9 2922000046 FORERUNNER TUBE
10 4030000055 PLUG JB1000-M22x1.5-35
11 2901000006 WASHER
12 2922000011 TUBE OF BRAKE
13 2922000047 TUBE OF FRONT AXLE
14 2922000013 TEE OF THE OIL LINE
15 4011000455 BOLT
16 2922000049 TUBE OF FRONT AXLE
17 4120000089 BRAKE CONTROL VALVE
18 2922000058 TUE TO AIR RESERVOIR
19 2901000005 WASHER
20 2901000007 CONNECTOR
21 2922000059 TUBE TO BOOSTER
22 2922000016 CONNECTOR
23 2922000017 WASHER
24 2922000060 TUBE TO FRONT BOOSTER
25 2901000004 BOLT
26 2922000061 TUBE TO BRAKE VALVE
27 2922000015 TEE OF THE OIL LINE
28 4120000675 BOOSTER
29 4011000475 BOLT
30 2922000068 TUBE FROM AIR RESERVOIR TO DUMMY PLATE
31 2922000062 TUBE TO BACK BOOSTER
32 2922000063 TUBE TO REAR AXLE
33 2922000018 TUBE OF REAR AXLE
34 2922000064 TUBE OF BRAKE
35 4011000477 BOLT
36 2922000053 AIR RESERVOIR
37 4011000560 BOLT
38 2901000019 TUBE
39 2901001136 TUBE
40 4120000084 AIR DYER
41 4011000488 BOLT
42 2901000008 HOLDER
43 2901000010 TUBE
44 4110000012 DISC BRAKE
45 2907000007 BRAKE DISH
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
