Каталог запасных частей к технике: SDLG LG956. IMPLEMENT HYDRAULIC SYSTEM

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5
5
6
7
7
8
9
10
11
12
12
12
13
13
14
15
16
16
16
17
18
19
19
19
20
20
20
21
22
23
24
25
25
26
27
28
29
30
30
30
31
31
31
32
33
34
35
36
36
36
36
36
36
36
36
36
36
36
37
38
38
38
38
38
38
38
39
39
39
39
39
39
39
39
39
39
40
41
42
42
43
44
45
46
47
48
49
49
50
50
51
52
53
54
54
54
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
Позиция на иллюстрации Заводской номер детали Название детали
1 4120001071 CONTROL SYSTEM LG12-936CZJG01
2 4011000474 BOLT
3 2912000002 BEARER
4 2912000003 OIL RETURN TUBE OF THE CONTROL VALVE
5 4030000130 O-RING
6 4041000010 FLANGE
7 4011000479 BOLT
8 4120000561 CONTROL VALVE SD32-18
9 2912000004 CLAMPING PLATE OF CONTROL VALVE
10 4011000056 BOLT
11 4011000057 BOLT
12 4015000168 WASHER
13 4013000011 NUT
14 4011000149 BOLT GB16674-M16x50EpZn-8.8
15 2912000005 FRAME
16 4011000447 BOLT
17 4011000557 U-BOLT JB/ZQ4321-42Zn-Q235A.F
18 2912000006 OIL INLET TUBE OF MULTIPLE VALVE
19 4041000156 PLUG LGB13501421
20 4030000238 O-RING
21 2912000007 PIN ROLL
22 4016000035 SPLIT PIN
23 2912000008 JOINT HEAD
24 4041000166 TUBE LGB161014120
25 4041000011 FLANGE
26 4011000477 BOLT
27 2912001097 CONTROL AXIS
28 4041000687 TUBE LGB165010130
29 4120000555 LIFT CYLINDER HSGF-165x90x767-1427
30 4030000026 O-RING
31 4011000473 BOLT
32 2913000002 OIL TUBE OF SMALL CHAMBER LEFT LIFTING CYLINDER
33 2913000003 OIL TUBE OF BIG CHAMBER LEFT LIFTING CYLINDER
34 2913000004 OIL TUBE OF SMALL CHAMBER RIGHT LIFTING CYLINDER
35 2913000005 OIL TUBE OF BIG CHAMBER RIGHT LIFTING CYLINDER
36 4011000475 BOLT
37 2913000006 SMALL CHAMBER TUBE OF LIFT CYLINDER
38 4041000056 FLANGE
39 4030000029 O-RING
40 2913000007 SMALL CHAMBER TUBE OF LIFT CYLINDER
41 2913000008 CLAMPING PLATE
42 4011000488 BOLT
43 2913000009 BIG CHAMBER TUBE OF LIFT CYLINDER
44 2913000010 BIG CHAMBER TUBE OF LIFT CYLINDER
45 2913000011 CAMPLE
46 4011000458 BOLT
47 2913000012 CLAMPING PLATE
48 4011000556 U-BOLT
49 4013000007 NUT
50 4015000162 Washer
51 2913000033 OIL PIPE OF LIFTING CYLINDER
52 4041000043 FLANGE
53 2913000013 THREE TUBE OF LIFT CYLINDER
54 4041000027 FLANGE
55 2913000014 THREE TUBE OF LIFT CYLINDER
56 2914000002 CLAMPING PLATE
57 4120000554 TILT CYLINDER HSGF-180x90x538-1092
58 2914000003 INDICATING ROD OF BUCKET
59 2914000004 CONDUIT OF INDICATING ROD
60 4041000169 TUBE LGB106012165
61 4011000309 BOLT
62 2914000005 BIG CHAMBER TUBE OF TILT CYLINDER
63 2914000006 CLAMP OF TILT CYLINDER
64 2914000016 OIL TUBE ASSEMBLY OF TILT CYLINDER B
65 2914000014 OIL TUBE ASSEMBLY OF TILT CYLINDER A
66 4017000018 CLAMP
67 2911000002 INTAKE OIL HOSE OF PUMP
68 2911000006 INTAKE OIL TUBE OF PUMP
69 4030000235 O-RING
70 4012000003 DOUBLE-SCREW BOLT
71 4120000401 WORKING PUMP CBGJ3100A
72 2911000004 SEALING PLATE OF PUMP
73 4041000690 TUBE LGB106413080
74 2911000005 VALVE BLOCK
75 4011000560 BOLT
76 4041000164 TUBE LGB105012120
