Каталог запасных частей к технике: SDLG LG953N. Cab
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33
34
35
36
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4190001769 | Catch | |
| 2 | 4011000458 | BOLT | |
| 3 | 4190000596 | CHECK OF UPPER GATE | |
| 4 | 4030000535 | OIL CUP | |
| 5 | 4190002359 | Protecting moulding | |
| 6 | 4190001768 | Pillar | |
| 7 | 4190002274 | Lock | |
| 8 | 4190000595 | COUNTER LOCK | |
| 9 | 4011000105 | BOLT | |
| 10 | 4015000036 | WASHER | |
| 11 | 4015000072 | WASHER | |
| 12 | 29290013421 | Bracket | |
| 13 | 29290013761 | Rear view mirror | |
| 14 | 29290013571 | Handle | |
| 15 | 29290013411 | Bracket | |
| 16 | 4014000055 | SCREW GB70.1-M12x30EpZn-8.8 | |
| 17 | 4011000560 | BOLT | |
| 18 | 29290013611 | Handle | |
| 19 | 29290013301 | Handle | |
| 20 | 4014000028 | SCREW | |
| 21 | 4190000956 | SEAL WASHER | |
| 22 | 29310012611 | Rubber cap | |
| 23 | 29290013551 | Protecting cover | |
| 24 | 29290013391 | Weatherstrip | |
| 25 | 4190002391 | Pin | |
| 26 | 29290013601 | Windscreen wiper | |
| 27 | 4011000276 | Bolt | |
| 28 | 29290013531 | Cover plate | |
| 29 | 29290013621 | Washer | |
| 30 | 29290013291 | Lock | |
| 31 | 29290013701 | Cover | |
| 32 | 4014000040 | SCREW | |
| 33 | 4190002273 | Lock | |
| 34 | 4190002588 | Wiper arm | |
| 35 | 4190002587 | Wiper motor | |
| 36 | 4190002589 | Wiper blade |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
