Каталог запасных частей к технике: SDLG LG953. LIFTING CYLINDER ASSENBLY
/33.gif)
1
2
2
2
2
2
2
2
3
3
4
5
6
7
8
8
8
8
8
8
9
10
11
12
12
12
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120000558 | LIFTING CYLINDER | |
| 2 | 4030000026 | O-RING | |
| 3 | 4011000473 | BOLT | |
| 4 | 29130001021 | SMALL CHAMBER TUBE OF LEFT LIFT CYLINDER | |
| 5 | 29130001171 | BIG CHAMBER TUBE OF LEFT LIFT CYLINDER | |
| 6 | 29130001031 | SMALL CHAMBER TUBE OF RIGHT LIFT CYLINDER | |
| 7 | 29130001181 | BIG CHAMBER TUBE OF RIGHT LIFT CYLINDER | |
| 8 | 4011000475 | BOLT | |
| 9 | 4030000029 | O-RING | |
| 10 | 29130008152 | TUBE | |
| 11 | 29130008181 | BIG CHAMBER RIGHE TUBE OF LIFTING | |
| 12 | 4041000043 | FLANGE | |
| 13 | 29130008201 | SMALL CHAMBER RIGHE TUBE OF LIFTING | |
| 14 | 29130011991 | LEFT BRACKET | |
| 15 | 29130008221 | BIG CHAMBER LEFT TUBE OF LIFTING | |
| 16 | 29130008241 | SMALL CHAMBER LEFT TUBE OF LIFTING | |
| 17 | 29130000111 | CLAMP | |
| 18 | 4011000458 | BOLT | |
| 19 | 4041001017 | U-BOLT LGB159-13040 | |
| 20 | 4013000007 | NUT | |
| 21 | 4015000162 | Washer | |
| 22 | 29130012011 | BRACKET | |
| 23 | 29130001211 | OIL PIPE OF LIFTING CYLINDER | |
| 24 | 4011000447 | BOLT | |
| 25 | 4011000474 | BOLT | |
| 26 | 4011000309 | BOLT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
