Каталог запасных частей к технике: SDLG LG953. LG9530B1 TORQUE CONVERTER SYSTEM
/4.gif)
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
26
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120000679 | RADIATOR ASS'Y | |
| 2 | 4120000597 | RADIATOR | |
| 3 | 4011000467 | BOLT | |
| 4 | 29050000031 | HOSE ASS'Y | |
| 5 | 4030000013 | O-RING | |
| 6 | 4120000238 | HOSE | |
| 7 | 29050001021 | SHIFT PRESS VITTA | |
| 8 | 4120000383 | CLIP | |
| 9 | 4120000098 | WATER-COOLED OIL RADIATOR | |
| 10 | 4011000082 | BOLT | |
| 11 | 4015000025 | Washer | |
| 12 | 29030001042 | MOTHERBOARD | |
| 13 | 4011000453 | BOLT | |
| 14 | 4015000203 | WASHER | |
| 15 | 29030001021 | CONNECTOR | |
| 16 | 2020900019 | PIPE JOINT | |
| 17 | 29030001031 | HOSE | |
| 18 | 2020900019 | PIPE JOINT | |
| 19 | 4120000034 | OIL FILTER | |
| 20 | 4011000107 | BOLT | |
| 21 | 4015000036 | WASHER | |
| 22 | 29040001021 | HOSE | |
| 23 | 29040001031 | HOSE | |
| 24 | 4110000011 | TORQUE CONVERTER | |
| 25 | 4011000207 | BOLT | |
| 26 | 4015000026 | WASHER | |
| 27 | 29040000041 | SEAL WASHER | |
| 28 | 4011000090 | BOLT | |
| 29 | 4011000089 | BOLT | |
| 30 | 29040007651 | HOLDER | |
| 31 | 4120000125 | JOINT BODY | |
| 32 | 4030000229 | O-RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
