Каталог запасных частей к технике: SDLG LG952H. STEERING CYLINDER (371401)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Позиция на иллюстрации Заводской номер детали Название детали
1 4120002378001 PISTON ROD
2 4120000560004 Sealing member aggregate
3 4120000560008 Cylinder cover
4 4120000560004 Sealing member aggregate
5 4120000560004 Sealing member aggregate
6 4120000560004 Sealing member aggregate
7 4120000560004 Sealing member aggregate
8 4120000560004 Sealing member aggregate
9 4120000560004 Sealing member aggregate
10 4120000560011 Piston
11 4120000560004 Sealing member aggregate
12 4120000560004 Sealing member aggregate
13 4120002378002 CYLINDER BODY
14 4120000560013 Holding block
15 4021000199 SPHERICAL PLAIN BEARING
16 4015000261 CHECK RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
